Airtac 6TV Solenoid Valve 6TV0500M9F
2、Internal exhaust structure collects pilot gas for centralized discharge through R port;
3、Aluminum alloy extruded body with precision-machined internal bore to significantly enhance flow efficiency;
4、Optional threaded connection type for integration with valve manifolds via base mounting, saving installation space.
Category: Solenoid Valves , Brand: AirTAC , Series: 6TV
AirTAC 6TV0500M9F Solenoid Valve Specifications
- Model: 6TV0500M9F
- Type: 5/2-way double solenoid (bi-stable)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.1–1.0 MPa
- Voltage options: DC12V, DC24V, AC110V, AC220V
- Flow capacity: 750 L/min (ANR)
- Response time: ≤30ms (at 0.5MPa)
- Weight: 420g ±5%
- Dimensions: 60mm(L) × 50mm(W) × 98mm(H)
- Seal material: FKM fluorocarbon (high temp variant available)
- Temperature range: -10℃ to 80℃ (extended to 120℃ with FKM seals)
- Power consumption: 1.8W (DC), 3.5VA (AC)
- Protection rating: IP67 (dustproof & temporary immersion)
- Port thread depth: 12mm (minimum engagement)
- Cycle rate: ≤5Hz (continuous operation)
High-flow directional control valve with dual coil latching mechanism, engineered for industrial automation requiring position memory during power loss. Features hardened brass construction with electroless nickel plating for hydraulic oil compatibility. Requires 5μm filtered compressed air with ISO 8573-1:2010 Class 3.2.4 air quality.
- Plastic injection molding machine clamp control
- Automated assembly line cylinder sequencing
- Textile machinery air circuit switching
- CNC tool changers with position retention
- Electroplating line hoist controls
Installation note:
Mount with vibration-damping brackets in high-cycle applications.
Use Loctite 243 on pipe threads. Allow 20-minute burn-in period
before full load operation. Manual override requires 5N·m torque limit.
| Property | Property Value |
|---|---|
| sku | 6TV0500M9F |
| Initial Position | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Port Size | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Standard Voltage | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Type | Base |
