Airtac 6TV Solenoid Valve 6TV0510M5NCA200
2、Internal exhaust structure collects pilot gas for centralized discharge through R port;
3、Aluminum alloy extruded body with precision-machined internal bore to significantly enhance flow efficiency;
4、Optional threaded connection type for integration with valve manifolds via base mounting, saving installation space.
Category: Solenoid Valves , Brand: AirTAC , Series: 6TV
AirTAC 6TV0510M5NCA200 Solenoid Valve Specifications
- Model: 6TV0510M5NCA200
- Type: 5/2-way single solenoid (monostable)
- Port size: PT1/4 (G1/8 optional)
- Thread standard: ISO 228/1 (BSPP)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 2.2W (DC), 3.5VA (AC)
- Response time: ≤25ms (exhaust to port A)
- Flow rate: 750 l/min (ANR) at 0.5 MPa
- Seal material: NBR (Nitrile Butadiene Rubber)
- Temperature range: -5℃ to 80℃ (operating fluid), -20℃ to 60℃ (ambient)
- Protection rating: IP65 (dust-tight & water jet resistant)
- Weight: 295g ±5g (including connector)
- Dimensions: 60mm(L) × 40mm(W) × 80mm(H) (excluding fittings)
- Port thread depth: 12mm (PT1/4)
- Manual override: Built-in push button
High-flow 5-port solenoid valve with aluminum alloy body and stainless steel core tube, optimized for industrial automation systems requiring bidirectional cylinder control. Features low-hysteresis electromagnetic design with surge protection circuitry. Requires ISO 8573-1:2010 Class 3.4.2 compressed air (40μm filtration, dew point -25℃).
- Pneumatic cylinder reciprocation control in assembly lines
- Rotary actuator positioning in packaging machinery
- Clamping/unclamping systems in CNC fixtures
- Material handling equipment with dual-action cylinders
- Plastic injection molding machine ejectors
Installation guidelines:
Mount in vibration-free locations using M5 mounting screws (max torque 1.2N·m).
Maintain minimum 20mm clearance below valve for exhaust dispersion.
Lubricate seals with ISO VG32 turbine oil if used in dry air systems.
| Property | Property Value |
|---|---|
| sku | 6TV0510M5NCA200 |
| Initial Position | Normally Closed |
| Port Size | M5 |
| Standard Voltage | AC220V |
| Type | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
