Airtac 6TV Solenoid Valve 6TV0510M5NCB050
2、Internal exhaust structure collects pilot gas for centralized discharge through R port;
3、Aluminum alloy extruded body with precision-machined internal bore to significantly enhance flow efficiency;
4、Optional threaded connection type for integration with valve manifolds via base mounting, saving installation space.
Category: Solenoid Valves , Brand: AirTAC , Series: 6TV
AirTAC 6TV0510M5NCB050 Solenoid Valve Specifications
- Model: 6TV0510M5NCB050
- Type: 5/2-way mono-stable (spring return)
- Port size: G1/8 (ISO228 standard)
- Thread type: M5 subminiature piping
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 1.2W (DC), 2.3VA (AC)
- Response time: ≤15ms (exhaust to full open)
- Seal material: HNBR (Hydrogenated Nitrile) for oil/fuel resistance
- Temperature range: -5℃ to 80℃ (with condensation prevention)
- Protection class: IP67 (dustproof & temporary immersion)
- Weight: 0.32kg (including connector)
- Dimensions: 53mm(L) × 40mm(W) × 48mm(H)
- Flow rate: 350 NL/min (at 0.5MPa)
- Port orientation: ISO 5599-1 compliant manifold mounting
High-speed 5-port valve with dual pressure balance structure for stable operation under variable loads. Features an aluminum alloy body with hard anodized finish for chemical resistance. Integrated LED status indicator with surge protection circuitry. Compatible with vacuum applications (requires optional seal kit).
- Robotic end-effector tool changers
- Semiconductor wafer handling systems
- Bottle cap screwing machines
- Textile machinery tension control
- Plastic injection molding ejectors
- Food processing pneumatic circuits (NSF-H1 grease compatible)
Installation protocol:
Use M5×12mm stainless steel screws (max torque 0.4N·m). Maintain 0.5-1mm gap between manifold plates.
For vertical installation, orient coil upward to prevent debris accumulation. Lubricate with ISO VG32 turbine oil if used in dry environments.
| Property | Property Value |
|---|---|
| sku | 6TV0510M5NCB050 |
| Initial Position | Normally Closed |
| Port Size | M5 |
| Standard Voltage | DC24V |
| Type | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
