Airtac 6TV Solenoid Valve 6TV0510M5NCB200
2、Internal exhaust structure collects pilot gas for centralized discharge through R port;
3、Aluminum alloy extruded body with precision-machined internal bore to significantly enhance flow efficiency;
4、Optional threaded connection type for integration with valve manifolds via base mounting, saving installation space.
Category: Solenoid Valves , Brand: AirTAC , Series: 6TV
AirTAC 6TV0510M5NCB200 Solenoid Valve Specifications
- Model: 6TV0510M5NCB200
- Type: 5/2-way single solenoid, pilot-operated
- Port size: PT1/8 (M5 threaded connection)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Voltage: DC24V (±10%) / AC220V (50/60Hz)
- Power consumption: 2.2W (DC) / 3.0VA (AC)
- Response time: ≤15ms (open), ≤20ms (close)
- Seal material: Heat-resistant NBR (-5℃ to 80℃)
- Flow coefficient (Cv): 0.8
- Max air viscosity: 35 cSt
- Weight: 350g ±5% (with coil)
- Dimensions: 54mm(L) × 30mm(W) × 40mm(H)
- Protection rating: IP67 (coil), IP40 (valve body)
- Compliance: ISO 15407-1, CE, RoHS
High-speed 5-port pneumatic valve with manual override function, featuring brass main body and reinforced PPS coil housing. Designed for rapid cycling applications requiring precise directional control. Includes LED status indicator and surge protection circuit. Requires 5μm filtered/dried compressed air with ISO 8573-1:2010 Class 3.4.3 quality.
- Pneumatic cylinder sequencing in assembly lines
- Textile machinery air circuit control
- Semiconductor wafer handling systems
- Automated test equipment clamping
- Food processing packaging actuators
Installation guidance:
Mount in vibration-free environment using M5×16mm screws (1.2Nm torque).
Maintain ≥20mm clearance from metal surfaces for heat dissipation.
Lubricate using ISO VG32 turbine oil if air line is un-lubricated.
| Property | Property Value |
|---|---|
| sku | 6TV0510M5NCB200 |
| Initial Position | Normally Closed |
| Port Size | M5 |
| Standard Voltage | DC24V |
| Type | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
