Airtac 6TV Solenoid Valve 6TV0510M5NCC050
2、Internal exhaust structure collects pilot gas for centralized discharge through R port;
3、Aluminum alloy extruded body with precision-machined internal bore to significantly enhance flow efficiency;
4、Optional threaded connection type for integration with valve manifolds via base mounting, saving installation space.
Category: Solenoid Valves , Brand: AirTAC , Series: 6TV
AirTAC 6TV0510M5NCC050 Solenoid Valve Specifications
- Model: 6TV0510M5NCC050
- Type: 5/2-way monostable (single solenoid)
- Port size: PT1/8 (M5 threaded connection)
- Operating pressure: 0.1–1.0 MPa
- Voltage options: DC24V (±10%), AC110V/50-60Hz, AC220V/50-60Hz
- Weight: ~220g (including coil)
- Dimensions: 58mm(L) × 38mm(W) × 78mm(H)
- Flow capacity: 850 l/min (ANR)
- Seal material: FKM (Fluorocarbon rubber)
- Temperature range: -5℃ to 80℃ (non-freezing)
- Power consumption: 2.2W (DC24V), 4.5VA (AC)
- Response time: ≤15ms (at 0.5MPa)
- Protection rating: IP67 (coil protection)
- Porting pattern: ISO 5599-1 standard
High-flow directional control valve with manual override, featuring an aluminum alloy body with hard anodized treatment for enhanced corrosion resistance. The optimized spool structure ensures stable switching even under pressure fluctuations. Requires 5μm filtered lubricated/non-lubricated air. Compatible with DIN-type connectors for simplified wiring.
- Industrial automation assembly lines
- Plastic injection molding machine clamp control
- Textile machinery cylinder sequencing
- Automotive tire inflation systems
- Bottle capping/palletizing equipment
Installation note:
Install with proper mounting brackets (M5 screws, 0.49-0.59N·m torque).
Maintain ambient temperature below 80% RH. For horizontal mounting,
ensure exhaust ports face downward to prevent dust ingress.
| Property | Property Value |
|---|---|
| sku | 6TV0510M5NCC050 |
| Initial Position | Normally Closed |
| Port Size | M5 |
| Standard Voltage | AC 110V |
| Type | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
