Airtac 6TV Solenoid Valve 6TV0510M5NCC200
$29.06
Regular price
$36.56
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
6TV0510M5NCC200
Product type:
Tags:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Plug-in electrical connection design allows horizontal and vertical terminal mounting orientations to be freely interchangeable;
2、Internal exhaust structure collects pilot gas for centralized discharge through R port;
3、Aluminum alloy extruded body with precision-machined internal bore to significantly enhance flow efficiency;
4、Optional threaded connection type for integration with valve manifolds via base mounting, saving installation space.
Category: Solenoid Valves , Brand: AirTAC , Series: 6TV
2、Internal exhaust structure collects pilot gas for centralized discharge through R port;
3、Aluminum alloy extruded body with precision-machined internal bore to significantly enhance flow efficiency;
4、Optional threaded connection type for integration with valve manifolds via base mounting, saving installation space.
Category: Solenoid Valves , Brand: AirTAC , Series: 6TV
AirTAC 6TV0510M5NCC200 Solenoid Valve Technical Details
- Model Code Breakdown: 6TV0510M5NCC200
- 6TV: Miniature solenoid valve series
- 05: Port size code (PT1/8 equivalent)
- 10: 10mm orifice diameter
- M5: M5 threaded connection
- NC: Normally closed configuration
- C200: DC24V coil specification
- Valve Type: 5/2-way single solenoid pilot-operated
- Port Thread: M5×0.8 (G1/8 adaptor included)
- Operating Pressure Range: 0.1–1.0 MPa
- Voltage Tolerance: DC24V±10% (Customizable for AC110-240V)
- Flow Capacity: 700 l/min (ANR) at 0.5 MPa
- Response Time: ≤15ms (pressurized to full flow)
- Weight: 220g ±5% (with coil and accessories)
- Dimensions: 58mm(L) × 35mm(W) × 25mm(H)
- Seal Materials: HNBR main seals with FKM backup rings
- Ambient Temperature: -10℃ to 60℃ (60%RH non-condensing)
- Power Consumption: 2.2W @ 20℃ ambient
- Protection Class: IP67 (Dustproof/Immersion resistant)
- Cycle Life: ≥50 million operations (under rated conditions)
High-speed modular valve with integrated silencer, featuring dual-color LED status indication (red/green for power/activation). The low-inertia plunger design enables rapid cycling up to 20Hz. Compatible with ISO 15407-1 standards for pneumatic valve mounting interfaces.
Industrial Applications:
- High-speed sorting mechanisms in logistics systems
- Precision pneumatic grippers in robotic assembly lines
- Textile machinery thread control systems
- Semiconductor wafer handling equipment
- Mobile hydraulic system pilot controls
Operational Guidelines:
Requires 5μm filtered lubricated air (ISO 8573-1 Class 3.4.2).
Maximum allowable backpressure: 10% of inlet pressure.
For horizontal mounting, use retaining clip (accessory code: 6TV-CLIP2).
| Property | Property Value |
|---|---|
| sku | 6TV0510M5NCC200 |
| Initial Position | Normally Closed |
| Port Size | M5 |
| Standard Voltage | AC 110V |
| Type | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
