Airtac 6TV Solenoid Valve 6TV0510M5NCF050
2、Internal exhaust structure collects pilot gas for centralized discharge through R port;
3、Aluminum alloy extruded body with precision-machined internal bore to significantly enhance flow efficiency;
4、Optional threaded connection type for integration with valve manifolds via base mounting, saving installation space.
Category: Solenoid Valves , Brand: AirTAC , Series: 6TV
AirTAC 6TV0510M5NCF050 Solenoid Valve Specifications
- Model: 6TV0510M5NCF050
- Type: 5/2-way monostable (single solenoid) with manual override
- Port configuration: PT1/8 (G1/8) with M5 subminiature ports
- Operating pressure range: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 750 l/min (Cv=1.2) at 0.5 MPa
- Response time: ≤15ms (excitation), ≤20ms (de-excitation)
- Weight: 220g ±5% (with connector)
- Dimensions: 48mm(L) × 35mm(W) × 68mm(H) (excluding fittings)
- Seal material: FKM (Fluorocarbon Rubber) for chemical resistance
- Temperature range: -10℃ to 80℃ (non-freezing conditions)
- Power consumption: 2.2W (DC models), 3.5VA (AC models)
- Protection rating: IP67 (dustproof and temporary immersion protection)
- Port thread depth: 9mm (M5), 11mm (PT1/8)
- Max. switching frequency: 5Hz (lubricated), 3Hz (non-lubricated)
High-speed 5-port pneumatic valve with integrated manual override, designed for precision directional control in compact automation systems. Features low-hysteresis plunger design with copper-free aluminum alloy body for compatibility with cleanroom environments. Includes LED status indicator and surge protection circuitry.
- Multi-position cylinder control in SMT assembly lines
- Vacuum/pressure switching in semiconductor handling
- Packaging machine clamp sequencing
- Medical device pneumatic logic systems
- Beverage filling station actuator control
Installation guidelines:
Mount with 10mm clearance around valve body for heat dissipation. Use ISO 8573-1 Class 3
compressed air (max 5mg/m³ oil content). For vertical mounting, position coil upward.
Manual override requires 3mm hex key operation (clockwise for emergency shutoff).
| Property | Property Value |
|---|---|
| sku | 6TV0510M5NCF050 |
| Initial Position | Normally Closed |
| Port Size | M5 |
| Standard Voltage | DC12V |
| Type | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
