Airtac 6TV Solenoid Valve 6TV0510M5NCF200
2、Internal exhaust structure collects pilot gas for centralized discharge through R port;
3、Aluminum alloy extruded body with precision-machined internal bore to significantly enhance flow efficiency;
4、Optional threaded connection type for integration with valve manifolds via base mounting, saving installation space.
Category: Solenoid Valves , Brand: AirTAC , Series: 6TV
AirTAC 6TV0510M5NCF200 Solenoid Valve Specifications
- Model: 6TV0510M5NCF200
- Type: 5/2-way monostable (double solenoid optional)
- Port size: PT1/4 (G1/4 ISO228-1 standard)
- Thread type: M5 subminiature connectors
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Max flow rate: 850 l/min (Cv=1.2)
- Voltage: DC24V±10% (other options: DC12V/AC110V/AC220V via suffix code)
- Coil insulation: Class F (155℃)
- Response time: ≤15ms (energize)/≤20ms (de-energize)
- Weight: 450g ±5% (with connectors)
- Dimensions: 98mm(L) × 45mm(W) × 65mm(H)
- Seal material: FKM (Viton® equivalent) for high temp resistance
- Temperature range: -5℃ to 80℃ (fluid temp)/-20℃ to 60℃ (ambient)
- Power consumption: 2.4W (standard coil)/1.2W (power-saving coil)
- Protection rating: IP67 (coil)/IP40 (valve body)
- Port alignment: ISO 5599-1 compliant
- Cycle life: ≥50 million operations
High-flow 5-port valve featuring M5 micro connectors for space-constrained installations. The 6TV series uses a balanced spool design for consistent performance under pressure fluctuations. Optional manual override and LED indicator versions available (suffix codes: /MO and /L). Requires ISO 8573-1 class 3 filtered air (max 5μm particles).
- Multi-axis pneumatic actuator control in assembly robots
- Plastic injection molding machine clamp mechanisms
- CNC tool changers requiring rapid cylinder reversal
- Food processing lines with frequent valve cycling (FDA-compliant grease option)
- Semiconductor wafer handling vacuum/pressure systems
Installation protocol:
Mount horizontally with ports downward to prevent debris accumulation.
Use anti-vibration brackets in mobile applications. Lubricate every 5 million cycles
with ISO VG32 turbine oil (1-2 drops per port). Allow 15mm side clearance for heat dissipation.
| Property | Property Value |
|---|---|
| sku | 6TV0510M5NCF200 |
| Initial Position | Normally Closed |
| Port Size | M5 |
| Standard Voltage | DC12V |
| Type | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
