Airtac 6TV Solenoid Valve 6TV0510M5NOA050
2、Internal exhaust structure collects pilot gas for centralized discharge through R port;
3、Aluminum alloy extruded body with precision-machined internal bore to significantly enhance flow efficiency;
4、Optional threaded connection type for integration with valve manifolds via base mounting, saving installation space.
Category: Solenoid Valves , Brand: AirTAC , Series: 6TV
AirTAC 6TV0510M5NOA050 Solenoid Valve Specifications
- Model: 6TV0510M5NOA050
- Type: 5-port, 2-position (5/2-way) solenoid valve with internal pilot
- Port size: M5 threaded connections (ISO standard)
- Operation mode: Monostable with spring return
- Normal state: Normally open (NO) configuration
- Operating pressure range: 0.1–0.85 MPa (14.5–123 psi)
- Max flow rate: 850 l/min (ANR) at 0.5 MPa
- Voltage specification: DC24V (±10%)
- Power consumption: 1.6W (2.5W max during actuation)
- Response time: ≤15ms (exhaust to operation)
- Seal material: Heat-resistant NBR (Nitrile rubber)
- Temperature range: -5℃ to 60℃ (with 20%–80% RH non-condensing)
- Protection rating: IP67 (dust-tight and waterproof immersion up to 1m)
- Weight: 182g ±3g (without connectors)
- Dimensions: 65mm(L) × 35mm(W) × 50mm(H) (body only)
- Port thread depth: 8mm engagement (metric fine thread)
High-speed modular valve featuring dual-pressure operation capability and manual override. The optimized flow path design reduces pressure loss by 18% compared to previous generations. Electrolytic corrosion-resistant brass body with PTFE-coated spool ensures >10 million cycle durability. Requires 5μm filtered compressed air with oil mist (ISO 8573-1:2010 Class 4.4.2).
- High-speed sorting mechanisms in logistics automation
- Precision clamping circuits in CNC tool changers
- Vacuum generator control for pick-and-place robots
- Multi-axis actuator synchronization systems
- Plastic injection molding machine ejectors
Installation guidelines:
Mount in vibration-free environments using M4 mounting screws (max 0.5Nm torque).
Maintain ≥15mm clearance from adjacent components for heat dissipation.
Use anti-vibration washers in mobile applications. Lubricate seals with ISO VG32 turbine oil during maintenance.
| Property | Property Value |
|---|---|
| sku | 6TV0510M5NOA050 |
| Initial Position | Normally Open |
| Port Size | M5 |
| Standard Voltage | AC220V |
| Type | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
