Airtac 6V-F Base 6V0500M3F
2. Centralized inlet/exhaust ports and unified wiring harness routing ensure simplified troubleshooting and maintenance accessibility;
3. Modular design with high expandability allows flexible combinations and future expansions of connected directional control valve quantities;
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: 6V-F
AirTAC 6V-F Manifold Base 6V0500M3F Technical Specifications
- Model: 6V0500M3F
- Type: Modular manifold base for multiple valve assembly
- Port size: PT1/8 (G1/8 optional)
- Operating pressure: 0.15–0.95 MPa
- Voltage compatibility: Designed for use with DC12V/24V or AC110V/220V solenoid valves
- Weight: 320g ±5g
- Dimensions: 78mm(L) × 34mm(W) × 28mm(H)
- Material: Reinforced PA66 with glass fiber (30%)
- Seal type: Dual-layer NBR/PU seals
- Temperature resistance: -10℃ to 80℃ (continuous operation)
- Port configuration: 5 stations with M5 mounting threads
- Flow capacity: 650 L/min (Cv value 1.2)
- Surface treatment: Anti-corrosion anodizing
High-density modular base engineered for multi-valve stacking in compact pneumatic systems. Features integrated air passages with leak-proof design and vibration-resistant mounting slots. The staggered port arrangement minimizes pressure drop across connected valves. Compatible with 6V series valves using M3 mounting screws (included).
- Multi-axis robotic end effectors
- Automated assembly line control clusters
- Textile machinery pneumatic circuits
- Semiconductor handling equipment
- Multi-cylinder sequencing systems
Installation guidelines:
Apply thread sealant on port connections (not included).
Maximum recommended torque: 1.5N·m for valve mounting screws.
Use parallel alignment tool (PN: ABT-6V) for multi-base combinations.
| Property | Property Value |
|---|---|
| sku | 6V0500M3F |
