Airtac 7V-F Solenoid Valve Manifold 7V100M10F
2、Centralized air inlet/exhaust ports and integrated wiring simplify troubleshooting during maintenance:
3、Flexible modular configuration with expandable design - Allows arbitrary combination and expansion of connected directional control valves quantity;
Category: Solenoid Valve Bases , Brand: AirTAC , Series: 7V-F
AirTAC 7V-F Series Valve Manifold Base 7V100M10F Technical Details
- Model: 7V100M10F (7V-F Series Modular Base)
- Type: Modular manifold base for solenoid valve assembly
- Port configuration: 10 stations (expandable via side connectors)
- Port size: G1/8 (ISO228 standard)
- Max operating pressure: 1.0 MPa
- Body material: Aluminum alloy (anodized surface treatment)
- Seal material: HNBR rubber (-20℃ to 150℃)
- Flow capacity: 750 Nl/min (at 0.5 MPa)
- Weight: 0.3 kg (base only)
- Dimensions: 100mm(L) × 50mm(W) × 40mm(H) per station block
- Surface roughness: Ra ≤3.2μm (air passageways)
- Mounting: ISO 4401-03-02-0-94 standard interface
- Vibration resistance: 10-55Hz, 1.5mm amplitude
Precision-engineered modular base for building multi-valve pneumatic control systems. Features optimized flow paths with minimal pressure drop and integrated sealing grooves for leak-proof connections. Compatible with 7V-F series valves and accessories. Base units can be combined laterally using M5×20 screws (max 10 bases in series).
- Automated assembly line valve clusters
- Multi-axis pneumatic actuator control systems
- Textile machinery air circuit distribution
- Semiconductor manufacturing equipment
- Packaging machine sequential control units
Installation protocol:
Apply 0.3-0.5Nm torque during valve mounting. Use PTFE sealing tape
on pipe threads. For multi-base configurations, align datum surfaces
within ±0.1mm tolerance. Perform pressure test at 1.5× working pressure
after assembly.
- End plates: 7V100-01 (standard), 7V100-02 (with pressure gauge port)
- Mounting kits: RK-07 series brackets
- Fieldbus options: IO-Link communication modules (7V-IO series)
| Property | Property Value |
|---|---|
| sku | 7V100M10F |
