Airtac 7V-F Solenoid Valve Manifold 7V100M16F
2、Centralized air inlet/exhaust ports and integrated wiring simplify troubleshooting during maintenance:
3、Flexible modular configuration with expandable design - Allows arbitrary combination and expansion of connected directional control valves quantity;
Category: Solenoid Valve Bases , Brand: AirTAC , Series: 7V-F
AirTAC 7V-F Series Manifold Base 7V100M16F Technical Specifications
- Model: 7V100M16F
- Type: Multi-station manifold base for 3/2-way valves
- Port configuration: 16 stations (1 inlet + 1 exhaust)
- Port thread size: G1/8 (ISO228 standard)
- Max operating pressure: 1.0 MPa
- Compatible voltage: Matches mounted solenoid coils (DC12V-AC220V)
- Weight: 680±10g
- Dimensions: 199mm(L) × 32mm(W) × 44mm(H)
- Material: Reinforced PA66 (30% glass fiber)
- Seal type: Integrated NBR gasket with dust-resistant lip
- Temperature tolerance: -5℃ to 80℃ (with intermittent 100℃ peak)
- Flow capacity: 450 NL/min (ANR) per station
- Mounting pattern: ISO 15407-1 compliant
Modular manifold base enabling centralized control of multiple pneumatic circuits. Features zero-leakage design with optimized flow channels for reduced pressure drop. The staggered port arrangement allows tool-free valve mounting and simplified tubing routing. Compatible with 7V-F series valves using M5 mounting screws (included).
- Multi-axis pneumatic actuator synchronization
- Automated production line cluster control
- Textile machinery air distribution systems
- Plastic injection molding machine sequencing
- Robotic end-effector tool switching
Installation protocol:
Apply 2.0-2.5Nm torque during valve mounting. Use PTFE tape on pipe threads.
For multi-block assemblies, limit stack height to 5 units maximum.
Perform monthly air purge through base exhaust ports.
| Property | Property Value |
|---|---|
| sku | 7V100M16F |
