Airtac 7V-F Solenoid Valve Manifold 7V100M7F
2、Centralized air inlet/exhaust ports and integrated wiring simplify troubleshooting during maintenance:
3、Flexible modular configuration with expandable design - Allows arbitrary combination and expansion of connected directional control valves quantity;
Category: Solenoid Valve Bases , Brand: AirTAC , Series: 7V-F
AirTAC 7V-F Series Valve Manifold Base 7V100M7F Technical Details
- Model: 7V100M7F (7V-F Series)
- Type: Modular solenoid valve manifold base
- Port size: PT1/4 (G1/4 optional)
- Number of stations: Single
- Flow capacity: 650 L/min (Cv=1.1)
- Operating pressure: 0.1–1.0 MPa
- Voltage compatibility: DC12V/24V, AC110V/220V (requires matching solenoid coil)
- Weight: 298g ±5g
- Dimensions: 72mm(L) × 54mm(W) × 42mm(H)
- Body material: Reinforced PA66 (30% glass fiber)
- Seal material: HNBR rubber (-20℃ to 150℃)
- Temperature range: -5℃ to 80℃ (with intermittent peaks to 100℃)
- Port thread depth: 12mm
- Mounting pattern: ISO 5599-1 standard
- Protection rating: IP67 (when properly assembled)
High-flow modular base designed for multi-valve stacking in centralized pneumatic systems. Features precision-molded sub-bases with leak-proof O-ring seals and color-coded port markings (P: red, A: blue, B: green, R/S: yellow). Includes built-in silencer chamber and anti-vibration mounting lugs.
- Automated assembly line clamping systems
- Plastic injection molding machine sequences
- Textile machinery pneumatic circuits
- Robotic end-effector control modules
- Semiconductor wafer handling equipment
Installation protocol:
Apply 3-5Nm torque during manifold stacking. Use M5x16mm mounting screws (ISO 4762) with spring washers.
Always perform pneumatic circuit flushing before initial operation. Lubricate O-rings with PAG oil if stored >12 months.
| Property | Property Value |
|---|---|
| sku | 7V100M7F |
