Airtac 7V Solenoid Valve 7V0510M5A050
2. Internal exhaust structure collects pilot gas and discharges centrally through R/S ports;
3. Aluminum alloy die-casting body with optimized flow path design enhances flow capacity;
4. Available in threaded or quick-connect versions, compatible with manifold base integration for space-saving installation.
Category: Solenoid Valves, Brand: Airtac, Series: 7V
AirTAC 7V0510M5A050 Solenoid Valve Technical Details
- Model: 7V0510M5A050
- Type: 5/2-way monostable (single solenoid)
- Port size: M5 x 0.8 (ISO standard)
- Operating pressure: 0.1–0.9 MPa (14.5–130.5 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (±10% 50/60Hz), AC220V (±10% 50/60Hz)
- Flow capacity: 750 l/min (Cv=1.2 at 0.5 MPa)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Weight: 210g ±5g (with connector)
- Dimensions: 58mm(L) × 34mm(W) × 52mm(H)
- Seal material: HNBR (Hydrogenated Nitrile) for improved oil resistance
- Temperature range: -10℃ to 80℃ (non-freezing conditions)
- Power consumption: 1.5W (DC), 3.5VA (AC)
- Protection rating: IP67 (dust tight and protected against temporary immersion)
- Port thread depth: 9mm (minimum engagement)
High-flow directional control valve with manual override, featuring brass alloy body for enhanced corrosion resistance in humid environments. The 5/2-way configuration enables precise control of double-acting actuators. Equipped with LED status indicator and surge protection diode for DC models.
- Pneumatic cylinder sequencing in assembly lines
- Textile machinery clutch control
- Bottle capping machine actuator control
- Automated welding equipment tool changers
- Cleanroom compatible production systems
Installation protocol:
Mount with DIN43650 standard connector facing downward to prevent debris accumulation.
Use copper-free anti-seize compound on threads. Requires 5μm filtration with automatic drain.
| Property | Property Value |
|---|---|
| sku | 7V0510M5A050 |
| Port Size | M5 |
| Standard Voltage | AC220V |
