Airtac 7V Solenoid Valve 7V0510M5B050
2. Internal exhaust structure collects pilot gas and discharges centrally through R/S ports;
3. Aluminum alloy die-casting body with optimized flow path design enhances flow capacity;
4. Available in threaded or quick-connect versions, compatible with manifold base integration for space-saving installation.
Category: Solenoid Valves, Brand: Airtac, Series: 7V
AirTAC 7V0510M5B050 Solenoid Valve Specifications
- Model: 7V0510M5B050
- Type: 5-port 2-position single solenoid (pilot-operated)
- Port size: PT1/8 (M5 threaded option available)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 180g ±5g (without connector)
- Dimensions: 50mm(L) × 30mm(W) × 70mm(H) (body only, exclude ports)
- Seal material: Heat-resistant NBR (Nitrile rubber)
- Temperature tolerance: -20℃ to 80℃ (with <40℃ recommended for optimal seal life)
- Power consumption: ≤2.5W (DC models), ≤3.5VA (AC models)
- Protection class: IP67 (dust-tight and protected against temporary immersion)
- Response time: ≤15ms opening / ≤20ms closing (at 0.5MPa)
- Service life: >10 million cycles (under rated conditions)
- Flow coefficient (Cv): 0.65 (Kv: 0.75)
- Port thread depth: 10mm (minimum engagement required)
High-flow miniaturized solenoid valve with ISO 5599-1 interface pattern, featuring brass main body with anodized aluminum solenoid housing. The optimized spool design reduces internal leakage to <5 bubbles/min under 0.5MPa air pressure. Includes manual override button for system debugging and features surge protection circuitry in the coil assembly.
- Multi-axis pneumatic actuator control in robotic systems
- Vacuum/pressure switching in semiconductor handling equipment
- Clamping sequence control in CNC machining centers
- Compressed air distribution in automotive assembly lines
- Batch processing systems in pharmaceutical packaging
Installation guidelines:
Mount in any orientation but avoid direct water impingement. Use 5μm filtration with automatic drainage.
For AC voltage models, maintain supply voltage fluctuation within ±10%. Replace seals every 3 years under
continuous operation (20℃~60℃ environment recommended).
| Property | Property Value |
|---|---|
| sku | 7V0510M5B050 |
| Port Size | M5 |
| Standard Voltage | DC24V |
