Airtac ACA Standard Automatic Compensation Hydraulic Shock Absorber ACA0806-3N
2. Monolithic structure withstands extreme pressure; Fully threaded external housing facilitates installation and adjustment while maintaining superior heat dissipation.
3. High-hardness stainless steel spindle enhances impact resistance and corrosion resistance, ensuring reliable operation in harsh operating conditions.
4. Specialized oil-injection technology ensures consistent damping performance and operational stability.
5. Compact profile design with industry-leading energy absorption capacity.
6. Proprietary lubricant as damping medium delivers stable buffering performance across wide temperature ranges (-20°C to +80°C).
Category: Hydraulic Shock Absorbers | Brand: AirTAC | Series: ACA Self-Compensating
AirTAC ACA0806-3N Standard Auto-Compensating Hydraulic Shock Absorber Specifications
- Model: ACA0806-3N
- Type: Single-cylinder auto-compensating design
- Thread size: M8×1.25 mounting thread
- Max. impact energy: 0.45 Nm/cycle
- Max. impact speed: 1.5 m/s
- Max. load capacity: 18 kg
- Adjustment method: Automatic viscosity compensation
- Operating temperature: -10℃ to 80℃
- Fluid type: ISO VG32 hydraulic oil
- Seal material: HNBR with PTFE coating
- Housing material: Chrome-plated steel cylinder
- Weight: 0.52 kg ±5%
- Dimensions: 82mm(L) × 20mm(Ø) × 20mm(rod diameter)
- Impact stroke: 6mm (adjustable via internal valve)
- Return time: ≤1.2 seconds (full stroke recovery)
- Protection rating: IP54 (dust protected & water resistant)
Precision-engineered hydraulic damper with automatic wear compensation, featuring a dual-chamber design that maintains consistent damping force throughout 50,000+ cycles. The nitrogen-assisted rebound system ensures rapid resetting, while the chrome-plated surface resists corrosion in humid environments (salt spray test passed 96hrs). Includes built-in debris exclusion grooves.
- Robotic arm joint shock absorption
- CNC machine tool automatic feed mechanisms
- High-speed packaging equipment stoppers
- Automated warehouse shuttle cart deceleration
- Press machine ram guidance systems
Installation protocol:
Mount vertically with impact direction aligned to piston axis.
Perform 10-15 test cycles before full operation. Relubricate every
500,000 cycles using ISO VG32 oil (2-3 drops via grease nipple).
Avoid side loads exceeding 5N. Not suitable for continuous
impact frequencies above 120 cycles/minute. Maintain ambient
temperature above -5℃ during cold starts.
| Property | Property Value |
|---|---|
| sku | ACA0806-3N |
| External Thread | M8 |
| Stroke | <6mm> |
| Speed Code | Low Speed (Heavy Load) |
| Bumper Cap Code | Without Bumper Cap |
