Airtac ACA Standard Automatic Compensation Hydraulic Shock Absorber ACA1007-2
2. Monolithic structure withstands extreme pressure; Fully threaded external housing facilitates installation and adjustment while maintaining superior heat dissipation.
3. High-hardness stainless steel spindle enhances impact resistance and corrosion resistance, ensuring reliable operation in harsh operating conditions.
4. Specialized oil-injection technology ensures consistent damping performance and operational stability.
5. Compact profile design with industry-leading energy absorption capacity.
6. Proprietary lubricant as damping medium delivers stable buffering performance across wide temperature ranges (-20°C to +80°C).
Category: Hydraulic Shock Absorbers | Brand: AirTAC | Series: ACA Self-Compensating
AirTAC ACA1007-2 Auto-Compensating Hydraulic Shock Absorber Specifications
- Model: ACA1007-2
- Type: Standard auto-compensating hydraulic buffer
- Max. absorbed energy: 2.8 Nm/cycle
- Stroke length: 15 mm
- Max. impact velocity: 2.0 m/s
- Piston rod diameter: Φ10 mm
- Mounting type: Horizontal or vertical (dual orientation)
- Housing material: Chrome-plated steel
- Piston rod material: Stainless steel (SUS304)
- Seal material: NBR with anti-wear additives
- Operating temperature: -10℃ to 80℃
- Fluid requirement: ISO VG15-32 hydraulic oil
- Weight: 0.54 kg ±2%
- Dimensions: 70mm(L) × 34mm(W) × 34mm(H)
- Surface treatment: Electrophoretic coating (10μm)
- Recovery time: ≤1.5 sec after full compression
Self-regulating hydraulic damper with automatic viscosity compensation mechanism, featuring maintenance-free operation and precision CNC-machined components. The twin-seal design prevents oil leakage even under 2 million cycle operations. Includes built-in buffer force adjustment through variable orifice design.
- High-speed press machine ram deceleration
- Robotic arm end-effector vibration control
- Packaging conveyor emergency stop systems
- CNC tool changer impact absorption
- Elevator car counterweight stabilization
Installation note:
Align piston rod axis within ±0.5° of impact direction. Pre-lubricate with specified oil before first use.
Perform 5-10 test strokes at 50% load capacity during commissioning.
- Check oil level every 50,000 cycles
- Replace seals after 1 million cycles or 2 years
- Use only AirTAC AHF-22 replacement oil
| Property | Property Value |
|---|---|
| sku | ACA1007-2 |
| External Thread | M10 |
| Stroke | 7mm |
| Speed Code | Medium Speed (Medium Load) |
| Bumper Cap Code | Plastic Bumper Cap |
