Airtac ACA Standard Automatic Compensation Hydraulic Shock Absorber ACA1007-3N
2. Monolithic structure withstands extreme pressure; Fully threaded external housing facilitates installation and adjustment while maintaining superior heat dissipation.
3. High-hardness stainless steel spindle enhances impact resistance and corrosion resistance, ensuring reliable operation in harsh operating conditions.
4. Specialized oil-injection technology ensures consistent damping performance and operational stability.
5. Compact profile design with industry-leading energy absorption capacity.
6. Proprietary lubricant as damping medium delivers stable buffering performance across wide temperature ranges (-20°C to +80°C).
Category: Hydraulic Shock Absorbers | Brand: AirTAC | Series: ACA Self-Compensating
AirTAC ACA Standard Auto-Compensating Hydraulic Shock Absorber ACA1007-3N
- Model: ACA1007-3N
- Type: Auto-compensating oil-filled shock absorber
- Capacity: 3.0 N·m/cycle
- Material: S45C steel piston rod, aluminum alloy body
- Temperature range: -10℃ to 80℃
- Mounting style: Side mounting (horizontal/vertical)
- Piston diameter: 10mm
- Max. impact velocity: 0.8 m/s
- Adjustment type: Automatic viscosity compensation
- Oil type: ISO VG32 hydraulic oil (pre-filled)
- Weight: 0.25kg ±5%
- Dimensions: 80mm(L) × 30mm(W) × 30mm(H)
- Surface treatment: Black anodized body, hard chrome-plated rod
- Reaction force: 60-120N (adjustable via preload)
- Seal material: HNBR with PTFE backup ring
High-performance self-regulating shock absorber with dynamic viscosity compensation, designed for precision damping in repetitive motion systems. Features zero-maintenance operation and anti-backdrive protection, with integrated dust wipers for contamination resistance. Optimized for 500,000+ cycle durability under ISO 9001 manufacturing standards.
- Pick-and-place robot end effectors
- High-speed packaging machine stoppers
- CNC tool changer mechanisms
- Automated conveyor sorting gates
- Textile machinery tension control systems
Installation note:
Mount with M6x1.0 fasteners (12.9 grade recommended). Ensure 0.5-1mm gap between
impact surface and piston tip during alignment. Perform 20-30 test cycles
before full operation to activate automatic compensation.
| Property | Property Value |
|---|---|
| sku | ACA1007-3N |
| External Thread | M10 |
| Stroke | 7mm |
| Speed Code | Low Speed (Heavy Load) |
| Bumper Cap Code | Without Bumper Cap |
