Airtac ACA Standard Automatic Compensation Hydraulic Shock Absorber ACA1210-1
2. Monolithic structure withstands extreme pressure; Fully threaded external housing facilitates installation and adjustment while maintaining superior heat dissipation.
3. High-hardness stainless steel spindle enhances impact resistance and corrosion resistance, ensuring reliable operation in harsh operating conditions.
4. Specialized oil-injection technology ensures consistent damping performance and operational stability.
5. Compact profile design with industry-leading energy absorption capacity.
6. Proprietary lubricant as damping medium delivers stable buffering performance across wide temperature ranges (-20°C to +80°C).
Category: Hydraulic Shock Absorbers | Brand: AirTAC | Series: ACA Self-Compensating
AirTAC ACA1210-1 Standard Auto-Compensating Hydraulic Shock Absorber Specifications
- Model: ACA1210-1
- Type: Auto-compensating oil buffer with temperature compensation
- Maximum impact energy: 0.5 N·m/cycle
- Maximum impact speed: 2.0 m/s
- Piston rod diameter: Ø12 mm
- Effective stroke: 10 mm
- Operating temperature: -20℃ to +80℃
- Housing material: Aluminum alloy (anodized surface)
- Seal material: HNBR with wear-resistant coating
- Oil type: ISO VG15 shock absorber fluid
- Adjustment method: Automatic viscosity compensation
- Weight: 0.82 kg ±3%
- Dimensions: 121mm(L) × 40mm(W) × 40mm(H)
- Mounting torque: 18-22 N·m
- Protection rating: IP67 (with optional dust cover)
Precision-engineered hydraulic damper featuring automatic oil compensation technology that maintains consistent damping force across temperature variations. The chrome-plated piston rod and multi-labyrinth seal structure ensure 500,000+ impact cycles with ≤0.02mm oil leakage. Includes anti-rotation design for stable linear motion absorption.
- High-speed pick-and-place robot end effectors
- Stamping press overtravel protection
- CNC tool changer impact absorption
- Automated warehouse shuttle damping
- Packaging machine feed mechanism stabilization
Installation note:
Mount horizontally with arrow direction matching impact force vector.
Perform initial 50-100 test cycles before full operation.
Relubricate every 1 million cycles using ISO VG15 oil (2±0.2ml).
| Property | Property Value |
|---|---|
| sku | ACA1210-1 |
| External Thread | M12 |
| Stroke | <10mm> |
| Speed Code | High Speed (Light Load) |
| Bumper Cap Code | Plastic Bumper Cap |
