Airtac ACA Standard Automatic Compensation Hydraulic Shock Absorber ACA1210-1N
$31.39
Regular price
$38.89
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACA1210-1N
Product type:
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Superior and smooth deceleration with adaptive damping performance: Automatically adjusts resistance under dynamic load impact.
2. Monolithic structure withstands extreme pressure; Fully threaded external housing facilitates installation and adjustment while maintaining superior heat dissipation.
3. High-hardness stainless steel spindle enhances impact resistance and corrosion resistance, ensuring reliable operation in harsh operating conditions.
4. Specialized oil-injection technology ensures consistent damping performance and operational stability.
5. Compact profile design with industry-leading energy absorption capacity.
6. Proprietary lubricant as damping medium delivers stable buffering performance across wide temperature ranges (-20°C to +80°C).
Category: Hydraulic Shock Absorbers | Brand: AirTAC | Series: ACA Self-Compensating
Installation protocol:
Mount with 10-15Nm torque using flat washer. Align impact direction with piston axis (±2° tolerance).
Perform 5-10 test cycles before full operation. Annual oil level inspection recommended.
2. Monolithic structure withstands extreme pressure; Fully threaded external housing facilitates installation and adjustment while maintaining superior heat dissipation.
3. High-hardness stainless steel spindle enhances impact resistance and corrosion resistance, ensuring reliable operation in harsh operating conditions.
4. Specialized oil-injection technology ensures consistent damping performance and operational stability.
5. Compact profile design with industry-leading energy absorption capacity.
6. Proprietary lubricant as damping medium delivers stable buffering performance across wide temperature ranges (-20°C to +80°C).
Category: Hydraulic Shock Absorbers | Brand: AirTAC | Series: ACA Self-Compensating
AirTAC ACA1210-1N Standard Auto-Compensating Hydraulic Shock Absorber Specifications
- Model: ACA1210-1N
- Type: Single-ended automatic oil compensation
- Piston diameter: Ø12mm
- Stroke: 10mm
- Max. impact energy: 0.6 N·m/cycle
- Max. impact speed: 1.5 m/s
- Operating temperature: -10℃ to 80℃
- Oil viscosity grade: ISO VG15-32
- Mounting thread: M12×1.5
- Housing material: Nickel-plated steel
- Seal material: HNBR rubber
- Weight: 480g ±5%
- Dimensions: 100mm(L) × 20mm(Ø) × 20mm(Ø) (excluding mounting thread)
- Rebound efficiency: ≥85%
- Corrosion resistance: 96hrs neutral salt spray test
Self-compensating hydraulic damper featuring automatic oil replenishment system eliminates manual maintenance. Precision CNC-machined components ensure consistent damping force across 200,000+ cycles. Sealed IP64-rated construction prevents oil leakage in dusty environments.
Typical Applications:
- Robotic arm end-effector vibration control
- CNC machine tool automatic door mechanisms
- Packaging line linear actuator end-stop damping
- Automated warehouse shuttle cart impact absorption
- Press machine counterbalance systems
Installation protocol:
Mount with 10-15Nm torque using flat washer. Align impact direction with piston axis (±2° tolerance).
Perform 5-10 test cycles before full operation. Annual oil level inspection recommended.
| Property | Property Value |
|---|---|
| sku | ACA1210-1N |
| External Thread | M12 |
| Stroke | <10mm> |
| Speed Code | High Speed (Light Load) |
| Bumper Cap Code | Without Bumper Cap |
