Description
1. Superior and smooth deceleration with adaptive damping performance: Automatically adjusts resistance under dynamic load impact.
2. Monolithic structure withstands extreme pressure; Fully threaded external housing facilitates installation and adjustment while maintaining superior heat dissipation.
3. High-hardness stainless steel spindle enhances impact resistance and corrosion resistance, ensuring reliable operation in harsh operating conditions.
4. Specialized oil-injection technology ensures consistent damping performance and operational stability.
5. Compact profile design with industry-leading energy absorption capacity.
6. Proprietary lubricant as damping medium delivers stable buffering performance across wide temperature ranges (-20°C to +80°C).
Category: Hydraulic Shock Absorbers | Brand: AirTAC | Series: ACA Self-Compensating
Installation protocol:
Mount vertically with impact direction aligned to central axis. Allow 20mm clearance
behind adjustment screw for maintenance. Pre-lubricate with light oil before initial use.
2. Monolithic structure withstands extreme pressure; Fully threaded external housing facilitates installation and adjustment while maintaining superior heat dissipation.
3. High-hardness stainless steel spindle enhances impact resistance and corrosion resistance, ensuring reliable operation in harsh operating conditions.
4. Specialized oil-injection technology ensures consistent damping performance and operational stability.
5. Compact profile design with industry-leading energy absorption capacity.
6. Proprietary lubricant as damping medium delivers stable buffering performance across wide temperature ranges (-20°C to +80°C).
Category: Hydraulic Shock Absorbers | Brand: AirTAC | Series: ACA Self-Compensating
AirTAC ACA1412-1 Standard Auto-Compensating Hydraulic Shock Absorber Specifications
- Model: ACA1412-1
- Type: Auto-oil-compensation hydraulic damper
- Max. absorbed energy: 1.5 J
- Max. impact velocity: 0.8 m/s
- Stroke: 12 mm (±1 mm)
- Applicable piston rod diameter: Φ12-16 mm
- Mounting thread: M14×1.5
- Operating temperature: -20℃ to +80℃
- Hydraulic oil type: ISO VG15 or equivalent
- Body material: Steel with hard chrome plating
- Adjustment mechanism: Automatic oil compensation
- Max. impact force: 1,200 N
- Cyclic frequency: ≤120 cycles/min
- Weight: 0.28 kg
- Dimensions: 68mm(L) × Φ24mm (Body diameter)
Self-regulating hydraulic damper featuring automatic viscosity compensation for consistent performance across temperature variations. Maintenance-free design with integrated dust ring prevents oil leakage and particle ingress. Hardened steel construction ensures 500,000+ impact cycles.
Typical Applications:
- High-speed packaging machinery stoppers
- CNC tool changer impact absorption
- Automated assembly line positioning units
- Robotic arm end-effector cushioning
- Press brake overstroke protection
Installation protocol:
Mount vertically with impact direction aligned to central axis. Allow 20mm clearance
behind adjustment screw for maintenance. Pre-lubricate with light oil before initial use.
Oil compensation procedure:
After 6 months continuous use, cycle damper 10× at 50% max load to activate
automatic compensation system. Check for smooth operation.
| Property | Property Value |
|---|---|
| sku | ACA1412-1 |
| External Thread | M14 |
| Stroke | 12mm |
| Speed Code | High Speed (Light Load) |
| Bumper Cap Code | Plastic Bumper Cap |
