Airtac ACA Standard Automatic Compensation Hydraulic Shock Absorber ACA1412-1N
2. Monolithic structure withstands extreme pressure; Fully threaded external housing facilitates installation and adjustment while maintaining superior heat dissipation.
3. High-hardness stainless steel spindle enhances impact resistance and corrosion resistance, ensuring reliable operation in harsh operating conditions.
4. Specialized oil-injection technology ensures consistent damping performance and operational stability.
5. Compact profile design with industry-leading energy absorption capacity.
6. Proprietary lubricant as damping medium delivers stable buffering performance across wide temperature ranges (-20°C to +80°C).
Category: Hydraulic Shock Absorbers | Brand: AirTAC | Series: ACA Self-Compensating
AirTAC ACA1412-1N Standard Auto-Compensating Hydraulic Shock Absorber Specifications
- Model: ACA1412-1N
- Type: Auto-compensating oil-filled shock absorber
- Maximum absorbed energy: 1.5 N·m/stroke
- Impact velocity range: 0.2-1.5 m/s
- Shaft diameter: 12 mm
- Stroke length: 14 mm
- Operating temperature: -20℃ to +80℃
- Oil capacity: 3.8 cm³
- Material: S45C steel shaft with aluminum alloy body
- Seal type: Double NBR seals with dust wiper
- Mounting orientation: Horizontal or vertical
- Weight: 0.75 kg
- Dimensions: 141mm(L) × 40mm(W) × 40mm(H)
- Surface treatment: Black anodized body with chrome-plated shaft
- Max. lateral load capacity: 150 N
- Adjustment mechanism: Automatic viscosity compensation
The ACA1412-1N features progressive damping with automatic oil compensation, maintaining consistent performance despite temperature fluctuations. Its through-shaft design allows dual-direction damping, while the integrated scraper ring prevents particulate contamination. The unit comes pre-filled with temperature-stable hydraulic oil (ISO VG 32 equivalent).
- Automated assembly line indexing mechanisms
- CNC machine tool axis end-stop cushioning
- Robotic arm joint motion control
- High-speed packaging equipment actuators
- Elevator car emergency braking systems
Installation guidelines:
Align impact direction with shaft axis (±2° tolerance). Perform 5-10 test strokes before full operation.
Re-lubricate sliding surfaces with light machine oil (ISO VG 15) every 50,000 cycles.
| Property | Property Value |
|---|---|
| sku | ACA1412-1N |
| External Thread | M14 |
| Stroke | 12mm |
| Speed Code | High Speed (Light Load) |
| Bumper Cap Code | Without Bumper Cap |
