Airtac ACA Standard Automatic Compensation Hydraulic Shock Absorber ACA1412-2N
2. Monolithic structure withstands extreme pressure; Fully threaded external housing facilitates installation and adjustment while maintaining superior heat dissipation.
3. High-hardness stainless steel spindle enhances impact resistance and corrosion resistance, ensuring reliable operation in harsh operating conditions.
4. Specialized oil-injection technology ensures consistent damping performance and operational stability.
5. Compact profile design with industry-leading energy absorption capacity.
6. Proprietary lubricant as damping medium delivers stable buffering performance across wide temperature ranges (-20°C to +80°C).
Category: Hydraulic Shock Absorbers | Brand: AirTAC | Series: ACA Self-Compensating
AirTAC ACA1412-2N Standard Auto-Compensating Hydraulic Shock Absorber Specifications
- Model: ACA1412-2N
- Type: Auto-compensating oil hydraulic damper
- Capacity: 2.0 J/stroke (max energy absorption)
- Maximum impact energy: 4.5 N·m
- Stroke: 12 mm (±1 mm)
- Piston rod diameter: Φ14 mm (chrome-plated steel)
- Mounting style: End thread M14×1.5
- Body material: Aluminum alloy with hard anodized finish
- Operating temperature: -10℃ to 80℃
- Protection class: IP64 (dust-tight & splash-resistant)
- Maximum impact speed: 2.0 m/s
- Adjustment type: Automatic oil compensation system
- Cycle frequency: ≤120 cycles/min
- Oil type: ISO VG15 hydraulic oil (pre-filled)
- Weight: 0.68 kg (with oil)
- Dimensions: 50mm(L) × 42mm(W) × 112mm(H)
Self-regulating hydraulic damper featuring automatic viscosity compensation for consistent performance across temperature variations. The through-shaft design allows bidirectional damping with 360° mounting flexibility. Includes integrated dust wiper seals and maintenance-free operation for industrial environments.
- Automated assembly line impact absorption
- CNC machine tool axis deceleration
- Packaging machinery end-stop damping
- Robotic arm joint motion control
- Elevator car buffer systems
Installation guidance:
Mount with 1-2mm pre-compression for optimal performance.
Avoid side-load forces exceeding 50N. Relubricate guide sleeve annually
using lithium soap-based grease. Do not disassemble oil chamber -
factory-sealed for lifetime lubrication.
| Property | Property Value |
|---|---|
| sku | ACA1412-2N |
| External Thread | M14 |
| Stroke | 12mm |
| Speed Code | Medium Speed (Medium Load) |
| Bumper Cap Code | Without Bumper Cap |
