Airtac ACED Double-acting Compact Cylinder ACED100X10B
The AirTAC Airtac ACED Double-acting Compact Cylinder ACED100X10B is a genuine double acting, double rod ISO 21287 compact air cylinder with a Ø100mm bore and 10mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder.
- BoreØ100 mm
- Stroke10 mm
- Port size1/4"
- Acting typeDouble acting, double rod
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACED Double-acting Compact Cylinder ACED100X10B
A double acting, double-rod compact cylinder built to ISO 21287, the ACED100X10B pushes a 100 mm piston through a short 10 mm stroke with a rod leaving both covers. Because each side works on the rod-side area, output is identical in either direction: 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa. The hard-anodized aluminium body carries a roller-burnished bore, and the S45C piston rod is hard-chrome plated for long service.
The short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so it slots into shallow press fixtures and clamping stations where a full-length body cannot. At 0.5 MPa, plan on roughly 2262 N of usable work, and the rod-side force equates to lifting about 192 kg vertically with a 2:1 margin. The through-rod resists rotation and side load, and the rear rod can carry a sensor flag. A fixed TPU bumper at each end absorbs end-of-stroke shock; speed range is 30-500 mm/s. Note that this plain cylinder drifts if air is lost - add a rod lock or pilot check where a load must be held.
Airtac ACED Double-acting Compact Cylinder ACED100X10B Technical Specifications
| Model | Airtac ACED Double-acting Compact Cylinder ACED100X10B |
|---|---|
| Series | ACED compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 10 mm |
| Acting type | Double acting, double rod |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 3770 N |
| 0.7 MPa | 5278 N |
| Max (@1.0 MPa) | 769 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used).
Model Code: Airtac ACED Double-acting Compact Cylinder ACED100X10B
| ACED | ISO 21287 compact cylinder (double-rod). |
|---|---|
| 100 | Bore size in mm. |
| ×10 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac ACED Double-acting Compact Cylinder ACED100X10B Is Used
Short-stroke press fixture
The 10 mm stroke and 3769.9 N rod-side force both ways suit a compact stamping or marking head on an electronics assembly line, where the through-rod keeps the tooling plate square under side load.
Symmetric push-pull gate
Equal force in both directions drives a sliding guard or indexing gate on packaging machinery without a return spring, with the rear rod carrying a position flag for the PLC.
Clamp-and-lift station
With about 192 kg of vertical lift capacity at a 2:1 margin, the cylinder raises and lowers a jig table in a machining cell; the shallow body fits under the table where a longer profile cylinder will not.
Is the Airtac ACED Double-acting Compact Cylinder ACED100X10B the Right Cylinder?
For this 100 mm bore the 10 mm stroke suits short-throw clamping and ejection moves; if you need more reach, the same bore runs to a 300 mm standard stroke, and stepping down to the 80 mm bore gives 2356.2 N at 0.5 MPa while the 125 mm bore delivers 5890.5 N. Ports are 1/4" (PT thread on this code) and the rod ends in a male thread thanks to the B code. FA/FB flange, LB foot and FTC brackets plus I/Y rod knuckles bolt to the ISO 21287 face. This unit has no magnet - order the -S code if you want CMSE / DMSE switch detection.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac ACED Double-acting Compact Cylinder ACED100X10B FAQ
As a double-rod cylinder, force is equal in both directions because both strokes use the rod-side area: 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa, with a peak of 768.8 kgf at 1.0 MPa. Operating pressure is 0.15-1.0 MPa (22-145 psi), proof pressure 1.5 MPa (215 psi), and speed 30-500 mm/s.
The ISO 21287 short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, with a fixed TPU bumper at each end and FA/FB flange, LB foot or FTC mounting on the standard face. Sensing is not included on this code: the magnet is the optional -S version, so order ACED100X10BS if you need CMSE or DMSE switches.
