Airtac ACED Double-acting Compact Cylinder ACED100X110B
The AirTAC Airtac ACED Double-acting Compact Cylinder ACED100X110B is a genuine double acting, double rod ISO 21287 compact air cylinder with a Ø100mm bore and 110mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder.
- BoreØ100 mm
- Stroke110 mm
- Port size1/4"
- Acting typeDouble acting, double rod
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACED Double-acting Compact Cylinder ACED100X110B
The ACED100X110B is a double acting, double-rod compact cylinder built to ISO 21287: a 100 mm bore pushes and pulls with the same 3769.9 N at 0.5 MPa (5277.9 N at 0.7 MPa) because a 20 mm rod exits both covers and both strokes work on the rod-side area. The male rod thread (B code) on each end bolts straight to your tooling, and the through-rod resists rotation and side load while the rear rod can carry a sensor flag. Speed range is 30-500 mm/s over 0.15-1.0 MPa (22-145 psi).
The hard-anodized aluminium body with a roller-burnished bore and S45C hard-chrome plated rod shrugs off wear in high-cycle service, and a fixed TPU bumper at each end absorbs end-of-stroke shock. The short ISO 21287 body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so it slots into presses and gantries where a full-length body will not fit. At 0.5 MPa the thrust equals about 384 kg of force, so halving for a 2:1 margin lets it lift roughly 192 kg vertically; plan on about 2260 N of real work at that pressure. Note it drifts if air is lost - add a rod lock or pilot check for a held load.
Airtac ACED Double-acting Compact Cylinder ACED100X110B Technical Specifications
| Model | Airtac ACED Double-acting Compact Cylinder ACED100X110B |
|---|---|
| Series | ACED compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 110 mm |
| Acting type | Double acting, double rod |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 3770 N |
| 0.7 MPa | 5278 N |
| Max (@1.0 MPa) | 769 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used).
Model Code: Airtac ACED Double-acting Compact Cylinder ACED100X110B
| ACED | ISO 21287 compact cylinder (double-rod). |
|---|---|
| 100 | Bore size in mm. |
| ×110 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac ACED Double-acting Compact Cylinder ACED100X110B Is Used
Press stamping fixture
The equal 3769.9 N push and pull at 0.5 MPa stamps and then retracts the die with identical force, while the 110 mm stroke clears a deep part nest on a transfer line.
Pallet lift-and-lower module
With a 2:1 margin the rod-side thrust lifts about 192 kg vertically; the through-rod keeps the lifting plate square and resists the side load of an off-center pallet.
Reciprocating saw carriage
A rod on each cover lets the rear rod drive a position flag while the front rod pushes the carriage, cycling at up to 500 mm/s with the TPU bumpers soaking up each reversal.
Is the Airtac ACED Double-acting Compact Cylinder ACED100X110B the Right Cylinder?
At 3769.9 N per side at 0.5 MPa, the 100 mm bore sits between the 80 mm bore (2356.2 N) and the 125 mm bore (5890.5 N) - step down if your load is under 2300 N, step up for heavy clamping. The 110 mm stroke is well inside the 300 mm max standard stroke for this bore, so it ships as a catalog item. FA/FB flange, LB foot and FTC brackets plus I/Y rod knuckles bolt to the ISO 21287 face. If you need position feedback, order the -S variant: the magnet is optional, and only the -S code accepts CMSE / DMSE switches. Ports are 1/4" (PT thread).
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac ACED Double-acting Compact Cylinder ACED100X110B FAQ
Yes - it is a double-rod cylinder, so force is equal both ways because both strokes use the rod-side area. Figures: 3769.9 N at 0.5 MPa, 5277.9 N at 0.7 MPa, and a maximum of 768.8 kgf at 1.0 MPa. Operating pressure is 0.15-1.0 MPa (22-145 psi) with 1.5 MPa (215 psi) proof pressure, air filtered to 40 um, speed 30-500 mm/s, temperature -20 to +70 C.
It is an ISO 21287 compact cylinder with a hard-anodized aluminium body, S45C hard-chrome plated 20 mm rod threaded male (B code) at both ends, and a fixed TPU bumper at each end of the 110 mm stroke. The short body saves about 50% of the mounting length of an ISO 15552 profile cylinder. FA/FB flanges, LB foot and FTC brackets plus I/Y knuckles fit the standard face. For CMSE or DMSE switches you must order the optional -S magnet code - this model without S has no magnet fitted.
