Airtac ACED Double-acting Compact Cylinder ACED100X150
The AirTAC Airtac ACED Double-acting Compact Cylinder ACED100X150 is a genuine double acting, double rod ISO 21287 compact air cylinder with a Ø100mm bore and 150mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder.
- BoreØ100 mm
- Stroke150 mm
- Port size1/4"
- Acting typeDouble acting, double rod
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACED Double-acting Compact Cylinder ACED100X150
A double acting compact cylinder built to ISO 21287, the ACED100X150 pushes a 100 mm bore through a 150 mm stroke with a piston rod leaving BOTH covers. Because each side sees the rod-side area, output is 3769.9 N at 0.5 MPa in either direction and 5277.9 N at 0.7 MPa - no push-versus-pull mismatch. The through-rod resists rotation and modest side load, and the rear rod can carry a sensor flag on gantry or press fixtures.
The short hard-anodized aluminium body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so it slots into tight machine frames and guarding. A fixed TPU bumper at each end absorbs end-of-stroke shock, and the S45C hard-chrome rod stands up to continuous cycling at 30-500 mm/s. For planning: treat roughly 2262 N (about 60% of the 0.5 MPa rating) as the usable working force, which corresponds to lifting around 192 kg vertically with a 2:1 margin.
Airtac ACED Double-acting Compact Cylinder ACED100X150 Technical Specifications
| Model | Airtac ACED Double-acting Compact Cylinder ACED100X150 |
|---|---|
| Series | ACED compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 150 mm |
| Acting type | Double acting, double rod |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 3770 N |
| 0.7 MPa | 5278 N |
| Max (@1.0 MPa) | 769 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used).
Model Code: Airtac ACED Double-acting Compact Cylinder ACED100X150
| ACED | ISO 21287 compact cylinder (double-rod). |
|---|---|
| 100 | Bore size in mm. |
| ×150 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac ACED Double-acting Compact Cylinder ACED100X150 Is Used
Symmetric press fixture
Equal 3769.9 N force from either rod end lets a machining cell clamp a housing from both sides of a 150 mm stroke without recalculating pull figures.
Counterbalanced lift column
A packaging line uses the rear rod to drive a guide flag while the front rod lifts about 192 kg of tray stack with a 2:1 margin at 0.5 MPa.
Bidirectional pusher station
On a bottling conveyor, the through-rod pushes crates off the line in either stroke direction at identical force, cycling 30-500 mm/s.
Is the Airtac ACED Double-acting Compact Cylinder ACED100X150 the Right Cylinder?
At 3769.9 N per side at 0.5 MPa, this bore sits between the 80 mm frame (2356.2 N) and the 125 mm frame (5890.5 N) - step down for lighter clamping, up for heavy press work. The 150 mm stroke is well inside the 300 mm standard limit for bore 100, so no made-to-order build is needed. Remember it drifts when air is lost; add a rod lock or pilot check if the load must stay put. Order FA/FB flange, LB foot or FTC brackets plus I/Y rod knuckles to suit the fixture, and add the -S code only if CMSE / DMSE switching is required - without it no magnet is fitted.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac ACED Double-acting Compact Cylinder ACED100X150 FAQ
Because a rod exits both covers, force is identical in both directions: 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa, both sides working on the rod-side area. At 1.0 MPa the theoretical maximum is 768.8 kgf (768.8 kgf equals the max force figure for this bore). Operating pressure is 0.15-1.0 MPa (22-145 psi) with 1.5 MPa (215 psi) proof pressure.
The ISO 21287 short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, with a fixed TPU bumper at each end and FA/FB, LB or FTC mounting on the standard face. Sensing is optional: order the -S version to get the magnet that works with CMSE / DMSE switches; the plain ACED100X150 has no magnet fitted.
