The AirTAC ACEJ125 Adjustable Compact Cylinder ACEJ125X100-100B is a genuine double acting, double rod, adjustable stroke ISO 21287 compact air cylinder with a Ø125mm bore and 100mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder.
A double acting AirTAC compact cylinder built to ISO 21287, the ACEJ125X100-100B pairs a 125 mm bore with a 100 mm stroke and an external stop screw that trims the extend stroke anywhere within the ordered 100 mm window. At 0.5 MPa it pushes 6135.9 N and pulls 5890.5 N, rising to 8590.3 N on the extend stroke at 0.7 MPa. The hard-anodized aluminium body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so this force class fits into presses and gantries that cannot house a full-length body.
The B code gives a male rod thread on the 25 mm hard-chrome-plated S45C rod, and the 1/4" port feeds air filtered to 40 um across a 0.15-1.0 MPa (22-145 psi) operating band at 30-500 mm/s. Because the stop screw is a mechanical end stop only, the piston still drifts if air is lost, so plan clamping around that. Fixed TPU bumpers absorb end-of-stroke energy at both ends.
| Model | Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-100B |
|---|---|
| Series | ACEJ compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø125 mm |
| Stroke | 100 mm |
| Acting type | Double acting, double rod, adjustable stroke |
| Port size | 1/4" |
| Rod thread | M16×2.0 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 5890 N |
| 0.7 MPa | 8247 N |
| Max (@1.0 MPa) | 1201 kgf |
ACEJ is double-rod: the rear rod that carries the stroke adjuster exits the rear cover, so both piston faces lose rod area. The rod-side (annular) area is used for both directions (conservative).
| ACEJ | ISO 21287 compact cylinder (adjustable-stroke). |
|---|---|
| 125 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -100 | Adjustable stroke window (mm the extend stroke can be shortened on site). |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (double rod, adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
The short ISO 21287 body, about 50% shorter in mounting length than an ISO 15552 profile cylinder, lets integrators mount serious force on overhead gantry press frames where a full-length body would not clear the structure.
Remember the adjuster shortens the extend stroke only and does not hold a load mid-stroke on air loss. FA flange or LB foot mounts bolt to the ISO 21287 face, and if you need position feedback, order the -S variant so CMSE / DMSE switches can be used; this model has no magnet fitted.
Quick checklist
The -100 code is a 100 mm adjustment window: an external stop screw shortens the 100 mm extend stroke on site, giving a usable range of 0-100 mm. It is a mechanical end stop, not a mid-stroke lock, so the piston still drifts if air pressure is lost. Operating pressure is 0.15-1.0 MPa (22-145 psi) and speed is 30-500 mm/s.
It is an ISO 21287 compact cylinder with a hard-anodized aluminium body, threaded aluminium front and back covers, a 25 mm hard-chrome-plated S45C rod with male thread (B code), a 1/4" PT port and fixed TPU bumpers at both ends. The body saves about 50% of the mounting length of an ISO 15552 profile cylinder. This version has no magnet fitted; order the -S code to enable CMSE or DMSE switches for end-position detection. FA flange and LB foot mounts bolt straight to the ISO 21287 face.
