Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-50SB
$237.25
Regular price
$244.75
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACEJ125X100-50SB
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with ISO 21287 standard for enhanced mounting dimension compatibility;
2. Threaded body-end cover connection ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and durability;
4. Asymmetrical bidirectional piston sealing design optimizes space efficiency while integrating oil retention functionality;
5. Compact architecture reduces installation footprint by 50% compared to ISO 15552 cylinders of equivalent bore size;
6. Triple-side sensor grooves on cylinder body enable flexible sensor mounting;
7. Integrated cushioning system effectively absorbs residual energy from high-speed operation and mechanical rotation;
8. Multiple standardized mounting accessories available for versatile configuration.
Category: Adjustable Cylinders , Brand: AirTAC , Series: ACEJ125
Installation notes:
2. Threaded body-end cover connection ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and durability;
4. Asymmetrical bidirectional piston sealing design optimizes space efficiency while integrating oil retention functionality;
5. Compact architecture reduces installation footprint by 50% compared to ISO 15552 cylinders of equivalent bore size;
6. Triple-side sensor grooves on cylinder body enable flexible sensor mounting;
7. Integrated cushioning system effectively absorbs residual energy from high-speed operation and mechanical rotation;
8. Multiple standardized mounting accessories available for versatile configuration.
Category: Adjustable Cylinders , Brand: AirTAC , Series: ACEJ125
AirTAC ACEJ125X100-50SB Adjustable Compact Cylinder Specifications
- Model: ACEJ125X100-50SB
- Type: Double-acting adjustable compact cylinder
- Bore diameter: 125 mm
- Stroke: 100 mm (±0.5 mm tolerance)
- Operating pressure: 0.1–0.9 MPa
- Cushion type: Adjustable pneumatic cushion (both ends)
- Port size: G1/2 (ISO standard)
- Mounting type: Basic foot mounting (SB series)
- Piston rod material: Hard chrome-plated stainless steel (SUS304)
- Cylinder tube material: Anodized aluminum alloy
- Seal material: Nitrile rubber (NBR) with wear-resistant ring
- Temperature range: -20℃ to 80℃
- Weight: 5.2 kg (including mounting accessories)
- Dimensions: 320mm(L) × 150mm(W) × 125mm(H)
- Max piston speed: 500–750 mm/s
- Lubrication: Pre-lubricated (oil-free operation possible)
A space-saving linear actuator with precision stroke adjustment, featuring dual adjustable air cushions for smooth deceleration. The anodized body provides corrosion resistance in humid environments. Integrated mounting slots allow direct installation in machinery frames. Compatible with ISO 15552 mounting accessories.
Typical Applications:
- High-speed pick-and-place systems in electronics assembly
- Clamping mechanisms in CNC machining centers
- Vertical lifting platforms in logistics automation
- Packaging machine ejector systems
- Plastic injection molding machine core pulls
Installation notes:
- Align piston rod axis with load direction within ±2° tolerance
- Use M10 mounting bolts (grade 8.8 or higher) for secure fixation
- Install speed controllers for optimal cushion adjustment
- Allow 20mm clearance around cushion screws for adjustment tools
| Property | Property Value |
|---|---|
| sku | ACEJ125X100-50SB |
| Adjustable Stroke | <50mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/4" Thread |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 125mm |
| Stroke | 100mm |
