Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-75S
2. Threaded body-end cover connection ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and durability;
4. Asymmetrical bidirectional piston sealing design optimizes space efficiency while integrating oil retention functionality;
5. Compact architecture reduces installation footprint by 50% compared to ISO 15552 cylinders of equivalent bore size;
6. Triple-side sensor grooves on cylinder body enable flexible sensor mounting;
7. Integrated cushioning system effectively absorbs residual energy from high-speed operation and mechanical rotation;
8. Multiple standardized mounting accessories available for versatile configuration.
Category: Adjustable Cylinders , Brand: AirTAC , Series: ACEJ125
AirTAC ACEJ125X100-75S Adjustable Compact Cylinder Specifications
- Model: ACEJ125X100-75S
- Type: Double-acting adjustable compact cylinder
- Bore size: Φ125mm
- Stroke: 100mm (customizable 50-500mm)
- Operating pressure: 0.1–0.9 MPa
- Cushion type: Adjustable air cushion at both ends
- Mounting style: Front flange (ISO/VDMA standard)
- Port size: G3/8 (M14×1.5 thread optional)
- Piston rod material: Chrome-plated steel (Cr-Mo)
- Tube material: Hard anodized aluminum alloy
- Seal material: NBR/PU (nitrile/polyurethane)
- Ambient temperature: -20℃ to 80℃
- Lubrication: Pre-lubricated (Oil-free operation possible)
- Weight: 3.85 kg ±2%
- Dimensions:
- Length: 298mm (full extension)
- Width: 165mm (mounting flange to rear)
- Height: 145mm (including cushion screws)
- Protection class: IP54 (standard), IP67 optional
- Cycle rate: ≤3 m/s piston speed
High-torque compact cylinder featuring precision-machined dual cushion adjustment screws with locknuts for vibration-sensitive applications. The diamond-knurled end covers enable tool-free cushion force adjustment (15° rotation range). Anti-rotation design prevents piston spin during operation. Integrated mounting slots accept M8 fasteners for multi-position installation.
- Palletizing robot end-effector actuation
- Die-casting machine core-pulling mechanisms
- Automotive welding fixture positioning
- Textile machinery tension control systems
- Pharmaceutical blister packaging presses
Installation note:
For vertical mounting, install M8x20 safety bolts (not included) through side slots.
Maintain 0.5-1mm gap between cushion screws and adjacent surfaces. Lubricate rod with
ISO VG32 hydraulic oil if operating below -10℃.
| Property | Property Value |
|---|---|
| sku | ACEJ125X100-75S |
| Adjustable Stroke | 75mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/4" Thread |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 125mm |
| Stroke | 100mm |
