Airtac ACJ Adjustable Auto-Compensating Hydraulic Shock Absorber ACA0806-1
1. Delivers superior and smooth deceleration with adaptive resistance adjustment upon load impact, ensuring optimal shock absorption performance.
2. Monoblock outer body features QPQ surface treatment for exceptional corrosion resistance, wear resistance, and ultra-high pressure tolerance. Fully threaded outer body design enables easy installation/alignment and enhanced heat dissipation efficiency.
3. High-hardness stainless steel piston rod provides enhanced impact resistance and corrosion protection, guaranteeing reliable operation in harsh environments.
4. Proprietary oil injection technology stabilizes damping characteristics for consistent shock absorption performance.
5. Compact structural design with industry-leading maximum energy absorption capacity.
6. Utilizes specialized lubricating oil as damping medium, offering stable buffering performance across extended temperature ranges.
Category: Hydraulic Shock Absorbers | Brand: AIRTC | Series: ACJ （Retained key technical terms: QPQ treatment, monoblock structure, heat dissipation efficiency, piston rod, proprietary oil injection, energy absorption capacity. Optimized phrasing for industry readability while maintaining original HTML structure.）
AirTAC ACJ Adjustable Auto-Compensating Hydraulic Shock Absorber ACA0806-1 Specifications
- Model: ACA0806-1 (ACJ Series)
- Maximum impact energy: 1.8 N·m/cycle
- Maximum impact velocity: 2.0 m/s
- Maximum load capacity: 300 N
- Stroke length: 6 mm (±1 mm)
- Rod diameter: M8×1.25 thread
- Installation type: Horizontal (axial load)
- Operating temperature: -10℃ to 80℃
- Hydraulic fluid: ISO VG15-32 turbine oil
- Adjustment mechanism: 270° rotary dial with 20-click positions
- Body material: Nickel-plated carbon steel
- Seal material: HNBR rubber (high-temperature NBR)
- Protection rating: IP54
- Weight: 0.65 kg ±3%
- Dimensions: 80mm(L) × 20mm(W) × 20mm(H)
Precision-engineered hydraulic damper with automatic wear compensation, featuring a dual-chamber design that maintains consistent damping force throughout 100,000+ cycles. The self-lubricating bronze bushing and hardened piston rod ensure smooth operation in high-cycle applications. Includes anti-rotation lock nut for vibration-resistant installation.
- Robotic material handling end effectors
- CNC tool changer impact absorption
- Automated packaging machine stoppers
- Elevator car emergency braking systems
- Precision stamping press counterbalance
Installation note:
Perform initial 50 "break-in" cycles at 50% load before full operation.
Adjust damping force clockwise for softer stops (↑ energy absorption)
or counter-clockwise for firmer stops. Recalibrate every 6 months or
50,000 cycles using the integrated wear indicator pin.
| Property | Property Value |
|---|---|
| sku | ACA0806-1 |
| External Thread | M8 |
| Stroke | <6mm> |
| Bumper Cap Code | Plastic Bumper Cap |
