Airtac ACJ Adjustable Auto-Compensating Hydraulic Shock Absorber ACA3625-1
1. Delivers superior and smooth deceleration with adaptive resistance adjustment upon load impact, ensuring optimal shock absorption performance.
2. Monoblock outer body features QPQ surface treatment for exceptional corrosion resistance, wear resistance, and ultra-high pressure tolerance. Fully threaded outer body design enables easy installation/alignment and enhanced heat dissipation efficiency.
3. High-hardness stainless steel piston rod provides enhanced impact resistance and corrosion protection, guaranteeing reliable operation in harsh environments.
4. Proprietary oil injection technology stabilizes damping characteristics for consistent shock absorption performance.
5. Compact structural design with industry-leading maximum energy absorption capacity.
6. Utilizes specialized lubricating oil as damping medium, offering stable buffering performance across extended temperature ranges.
Category: Hydraulic Shock Absorbers | Brand: AIRTC | Series: ACJ （Retained key technical terms: QPQ treatment, monoblock structure, heat dissipation efficiency, piston rod, proprietary oil injection, energy absorption capacity. Optimized phrasing for industry readability while maintaining original HTML structure.）
AirTAC ACJ Adjustable Auto-Compensating Hydraulic Shock Absorber ACA3625-1 Specifications
- Model: ACA3625-1
- Type: Adjustable oil hydraulic buffer with auto-compensation
- Max. impact energy: 7.5 N·m/cycle
- Max. impact velocity: 3.0 m/s
- Max. load capacity: 2000 N
- Stroke: 25 mm
- Installation: Horizontal or vertical (axial load only)
- Adjustment range: 5-20% energy absorption via hex key
- Operating temperature: -10℃ to +80℃
- Oil type: ISO VG15-32 hydraulic oil
- Housing material: Aluminum alloy with hard anodized finish
- Rod material: Chrome-plated steel
- Weight: 0.68 kg ±2%
- Dimensions: 62mm (D) × 36mm (W) × 95mm (H)
- Thread size: M36×1.5 mounting thread
- Rebound efficiency: ≥90%
Precision-engineered hydraulic damper featuring automatic viscosity compensation for consistent performance across temperature variations. The ACA3625-1 combines 360° adjustable damping force with wear-indicator window for maintenance prediction. Its double-sealed structure (primary polyurethane + secondary NBR seals) ensures leak-free operation even in high-cycle applications.
- High-speed pick-and-place robot end effectors
- CNC tool changer impact absorption
- Packaging machine stopper mechanisms
- Automated warehouse shuttle dampening
- Press brake tooling protection systems
Installation note:
Pre-lubricate threads with MOBILUX EP2 grease. Perform initial adjustment at 50% load capacity,
then fine-tune while monitoring piston rebound. Replace oil every 500,000 cycles or annually.
| Property | Property Value |
|---|---|
| sku | ACA3625-1 |
| External Thread | M36x1.5 |
| Stroke | <25 mm> |
| Bumper Cap Code | Plastic Bumper Cap |
