Airtac ACJ Adjustable Auto-Compensating Hydraulic Shock Absorber ACJ1210
1. Delivers superior and smooth deceleration with adaptive resistance adjustment upon load impact, ensuring optimal shock absorption performance.
2. Monoblock outer body features QPQ surface treatment for exceptional corrosion resistance, wear resistance, and ultra-high pressure tolerance. Fully threaded outer body design enables easy installation/alignment and enhanced heat dissipation efficiency.
3. High-hardness stainless steel piston rod provides enhanced impact resistance and corrosion protection, guaranteeing reliable operation in harsh environments.
4. Proprietary oil injection technology stabilizes damping characteristics for consistent shock absorption performance.
5. Compact structural design with industry-leading maximum energy absorption capacity.
6. Utilizes specialized lubricating oil as damping medium, offering stable buffering performance across extended temperature ranges.
Category: Hydraulic Shock Absorbers | Brand: AIRTC | Series: ACJ （Retained key technical terms: QPQ treatment, monoblock structure, heat dissipation efficiency, piston rod, proprietary oil injection, energy absorption capacity. Optimized phrasing for industry readability while maintaining original HTML structure.）
AirTAC ACJ1210 Adjustable Auto-Compensating Hydraulic Shock Absorber Specifications
- Model: ACJ1210
- Type: Adjustable oil-hydraulic buffer with automatic compensation
- Max. impact energy: 0.35 Nm/cycle
- Max. impact velocity: 0.8 m/s
- Max. load capacity: 15 kg (dynamic)/50 kg (static)
- Stroke: 10 mm (±1 mm adjustable)
- Outer diameter: Φ12 mm
- Rod diameter: Φ10 mm
- Mounting type: M12×1.5 threaded installation
- Body material: S45C steel with black oxide coating
- Piston material: Aluminum alloy (anodized)
- Operating temp: -5℃ to +80℃
- Oil type: ISO VG32 hydraulic oil
- Adjustment mechanism: 360° rotary knob with click-stops
- Weight: 0.25 kg ±5%
- Dimensions: 70mm(L) × 12mm(Φ) × 12mm(rod Φ)
Self-compensating hydraulic damper featuring automatic viscosity compensation for consistent performance across temperature variations. The dual-stage sealing system combines PTFE wipers with nitrile seals, achieving IP64 protection. Calibration marks on the adjustment knob enable precise damping force control from 20-200 N·s/m.
- High-cycle CNC turret tool changers
- Automated packaging machine end-stops
- Robotic arm joint motion control
- Elevator car counterweight guides
- Precision optical instrument stages
Installation protocol:
Mount vertically with impact direction aligned to piston axis. Perform 5-10 test cycles before locking adjustment knob.
Replenish oil through integrated fill port every 50,000 cycles using ISO VG32 fluid (viscosity 32 cSt @40℃).
| Property | Property Value |
|---|---|
| sku | ACJ1210 |
| External Thread | M12 |
| Stroke | <10mm> |
| Bumper Cap Code | Plastic Bumper Cap |
