This model is discontinued
AirTAC has phased out the MAL series. The drop-in replacement is ACED100X100 — same bore, stroke, output force, port and mounting, so it fits the same application. Simply order the ACED100X100 in place of this model. The ACE replacement is a current-production ISO 21287 compact cylinder in the same bore, stroke and force class, with a matching short body and the same mounting-accessory family, so it fits the same envelope. Confirm mounting-interface dimensions against the ACE datasheet before ordering.
Airtac ACPD Double Rod Compact Cylinder ACPD100X100
The AirTAC Airtac ACPD Double Rod Compact Cylinder ACPD100X100 is a double acting, double rod DIN-standard tight/compact air cylinder with a Ø100mm bore and 100mm stroke, 1/4" air ports and a hard-anodized aluminium body. This model is discontinued — the current-production replacement is the ACED100X100 (ISO 21287 ACE), in the same bore, stroke and force class.
- BoreØ100 mm
- Stroke100 mm
- Port size1/4"
- Acting typeDouble acting, double rod
- Rod threadM16×1.5
- StatusDiscontinued → ACED100X100
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACPD Double Rod Compact Cylinder ACPD100X100
A double acting compact cylinder with a rod through both covers, the ACPD100X100 delivers 3681.6 N in either direction at 0.5 MPa because both strokes work on the rod-side area. The 100 mm bore on a 100 mm stroke gives 5154.2 N at 0.7 MPa and up to 750.8 kgf at 1.0 MPa, equal push and pull. The hard-anodized aluminium body keeps the mounting length roughly half that of an ISO 15552 profile cylinder, so it suits heavy gantries and press fixtures with tight envelopes.
The through-rod resists rotation and side load and gives a symmetric mount, and the rear rod can carry a sensor flag while the front rod drives the tool. Fixed TPU bumpers sit at both ends and travel runs 30-500 mm/s on air filtered to 40 um at 0.15-1.0 MPa (22-145 psi). Plan on about 2200 N of real work at 0.5 MPa, which lifts roughly 188 kg vertically with a 2:1 margin. Note this model is discontinued: the current-production drop-in is the ISO 21287 ACED100X100, so confirm mounting dimensions before swapping.
Airtac ACPD Double Rod Compact Cylinder ACPD100X100 Technical Specifications
| Model | Airtac ACPD Double Rod Compact Cylinder ACPD100X100 |
|---|---|
| Series | ACPD DIN compact cylinder (discontinued) |
| Replacement | ACED100X100 |
| Bore size | Ø100 mm |
| Stroke | 100 mm |
| Acting type | Double acting, double rod |
| Port size | 1/4" |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACP datasheet (now discontinued). The ACED100X100 (ISO 21287) carries the same bore/stroke/force class; confirm mounting-interface dimensions against the ACE datasheet before installation. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G.
Theoretical Output Force (Ø100mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 3682 N |
| 0.7 MPa | 5154 N |
| Max (@1.0 MPa) | 751 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used).
Model Code: Airtac ACPD Double Rod Compact Cylinder ACPD100X100
| ACPD | DIN compact cylinder (double-rod, discontinued). |
|---|---|
| 100 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| S | Optional built-in magnet for sensor position sensing (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
Replacement mapping (swap P for E): ACP→ACE, ASP→ASE, ATP→ATE, ACPD→ACED, ACPJ→ACEJ. ACP-family: ACP (double acting), ASP / ATP (single acting push / pull), ACPD (double rod), ACPJ (adjustable stroke).
Where the Airtac ACPD Double Rod Compact Cylinder ACPD100X100 Is Used
Press fixture return
The 3681.6 N reverse stroke ejects stamped aluminium brackets from a die on the return run, matching the forward force so the tool clears every cycle.
Gantry Z-lift
A packaging line gantry uses the 100 mm stroke to lift about 188 kg of tooling vertically with a 2:1 margin, the through-rod keeping the head square.
Reciprocating conveyor pusher
Rods on both covers let a panel-transfer unit push cartons forward and pull the carriage back with equal 5154.2 N force at 0.7 MPa, no separate return cylinder.
Replacing the Airtac ACPD Double Rod Compact Cylinder ACPD100X100 with the ACED100X100
Size around the 3681.6 N figure at 0.5 MPa; if your load needs less, the ACPD80X100 offers 2356.2 N in the same stroke, and there is no larger bore in the family, so step to the ACED range or a bigger frame for more force. The piston drifts when air is lost, so add a rod lock or pilot check valve for a held load. This unit has no magnet fitted; order the -S code if you need CMSE or DMSE switches. Mount via FA/FB flange or LB foot on the ISO 21287 face, and specify the ACED100X100 as the replacement since ACPD is out of production.
Replacement checklist
- ✓ Current-production ACE → ACED100X100
- ✓ Same bore / stroke / force class
- ✓ Confirm ISO 21287 mounting dimensions
- ✓ Port/thread type (PT / G)
- ✓ Add -S for magnet if you need sensors
Airtac ACPD Double Rod Compact Cylinder ACPD100X100 FAQ
Yes, force is equal in both directions because a rod exits each cover and both strokes use the rod-side area. At 0.5 MPa you get 3681.6 N, at 0.7 MPa you get 5154.2 N, and the maximum is 750.8 kgf at 1.0 MPa. Operating range is 0.15-1.0 MPa (22-145 psi) with proof pressure of 1.5 MPa (215 psi), speed 30-500 mm/s, and the 1/4" port serves both chambers.
AirTAC no longer produces the ACPD family. The current drop-in is the ISO 21287 ACED100X100, which swaps the P for an E and matches the same 100 mm bore, 100 mm stroke and force class with the short compact body. Because the ACP was built to a DIN standard, confirm the ISO 21287 mounting dimensions and your FA/FB or LB bracket fit before you swap. This unit also has no magnet, so if you need CMSE or DMSE sensing on the replacement, order the ACED with the optional -S magnet code.
