Airtac ACPD Double Rod Compact Cylinder ACPD100X110S
2. Features threaded connections at both ends of the cylinder barrel for enhanced structural integrity and maintenance convenience;
3. Precision-machined interior with hard anodization treatment for superior wear resistance and durability;
4. Patented bidirectional sealing structure on piston ensures compact dimensions and integrated oil retention capability;
5. Space-saving compact design optimizes installation footprint;
6. Magnetic sensor groove along cylinder periphery enables flexible sensor mounting;
7. Multiple mounting accessories available for various configurations;
Category: Double-acting Cylinder | Brand: AirTAC | Series: ACPD
AirTAC ACPD100X110S Double Rod Compact Cylinder Specifications
- Model: ACPD100X110S
- Type: Double-acting compact cylinder with dual rod
- Bore size: 100mm
- Stroke: 110mm
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–1000 mm/s (cushioned)
- Port size: G3/8 (NPT1/4 optional)
- Mounting style: Basic (MF1) with optional foot/axial mounts
- Cushioning: Adjustable air cushion at both ends
- Ambient temperature: -20℃ to 80℃
- Piston material: Aluminum alloy with hard anodized surface
- Rod material: Chrome-plated carbon steel (S45C)
- Seal type: NBR (Nitrile) standard, optional FKM/Viton
- Weight: 4.8 kg (without accessories)
- Dimensions: 336mm(L) × 100mm(W) × 100mm(H)
- ISO standard: 15552 compliant design
- Protection rating: IP65 (rod gland area)
High-precision dual-rod cylinder featuring symmetrical force output and minimal lateral deflection. The compact profile (40% shorter than standard ISO cylinders) enables installation in space-constrained environments. Pre-installed magnetic piston (D-M9N sensor compatible) allows position feedback. Anti-rotation design maintains alignment during long-stroke operations.
- Precision alignment systems in semiconductor manufacturing
- Parallel gripper mechanisms for robotic arms
- Vertical lifting platforms in automotive assembly lines
- Position-stabilized clamping fixtures for CNC machining
- Synchronized motion systems requiring dual output force
Installation guidelines:
Maintain 0.5mm minimum clearance between rods during parallel installations.
Use rod-end bearings for angular misalignment compensation. Lubricate with ISO VG32
hydraulic oil if operating below -10℃. Maximum side load capacity: 200N.
| Property | Property Value |
|---|---|
| sku | ACPD100X110S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/4" Thread |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 110mm |
