This model is discontinued
AirTAC has phased out the MAL series. The drop-in replacement is ACED100X110SB — same bore, stroke, output force, port and mounting, so it fits the same application. Simply order the ACED100X110SB in place of this model. The ACE replacement is a current-production ISO 21287 compact cylinder in the same bore, stroke and force class, with a matching short body and the same mounting-accessory family, so it fits the same envelope. Confirm mounting-interface dimensions against the ACE datasheet before ordering.
Airtac ACPD Double Rod Compact Cylinder ACPD100X110SB
The AirTAC Airtac ACPD Double Rod Compact Cylinder ACPD100X110SB is a double acting, double rod DIN-standard tight/compact air cylinder with a Ø100mm bore and 110mm stroke, 1/4" air ports and a hard-anodized aluminium body. This model is discontinued — the current-production replacement is the ACED100X110SB (ISO 21287 ACE), in the same bore, stroke and force class.
- BoreØ100 mm
- Stroke110 mm
- Port size1/4"
- Acting typeDouble acting, double rod
- Rod threadM16×1.5
- StatusDiscontinued → ACED100X110SB
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACPD Double Rod Compact Cylinder ACPD100X110SB
A double acting, double-rod compact cylinder in the discontinued AirTAC ACPD series, the ACPD100X110SB pushes a 100 mm bore over a 110 mm stroke with a rod leaving both covers. Because both strokes work on the rod-side area, output is identical each way: 3681.6 N at 0.5 MPa and 5154.2 N at 0.7 MPa. The 25 mm through-rod resists rotation and side load, gives a symmetric mount, and lets the rear rod carry a sensor flag, while fixed TPU bumpers decelerate at each end. It runs on air filtered to 40 um at 0.15-1.0 MPa (22-145 psi), proof 1.5 MPa (215 psi), from -20 to +70 C, at 30-500 mm/s.
The hard-anodized aluminium body follows the short ISO 21287-class format, cutting roughly 50% of the mounting length of an ISO 15552 profile cylinder, so it slots into wide gantry lifts and heavy press fixtures where a full-length body will not reach. In practice, plan on about 2209 N (roughly 187 kg lifted vertically with a 2:1 margin) of real work at 0.5 MPa rather than the full rating. The B code gives a male M16x1.5 rod thread and the S code fits the optional magnet, so CMSE / DMSE switches can be mounted for end-position sensing. Note: this model is discontinued; the current-production drop-in is the ACED100X110, and you should confirm the ISO 21287 mounting dimensions before swapping.
Airtac ACPD Double Rod Compact Cylinder ACPD100X110SB Technical Specifications
| Model | Airtac ACPD Double Rod Compact Cylinder ACPD100X110SB |
|---|---|
| Series | ACPD DIN compact cylinder (discontinued) |
| Replacement | ACED100X110SB |
| Bore size | Ø100 mm |
| Stroke | 110 mm |
| Acting type | Double acting, double rod |
| Port size | 1/4" |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACP datasheet (now discontinued). The ACED100X110SB (ISO 21287) carries the same bore/stroke/force class; confirm mounting-interface dimensions against the ACE datasheet before installation. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G.
Theoretical Output Force (Ø100mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 3682 N |
| 0.7 MPa | 5154 N |
| Max (@1.0 MPa) | 751 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used).
Model Code: Airtac ACPD Double Rod Compact Cylinder ACPD100X110SB
| ACPD | DIN compact cylinder (double-rod, discontinued). |
|---|---|
| 100 | Bore size in mm. |
| ×110 | Stroke length in mm. |
| S | Optional built-in magnet for sensor position sensing (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
Replacement mapping (swap P for E): ACP→ACE, ASP→ASE, ATP→ATE, ACPD→ACED, ACPJ→ACEJ. ACP-family: ACP (double acting), ASP / ATP (single acting push / pull), ACPD (double rod), ACPJ (adjustable stroke).
Where the Airtac ACPD Double Rod Compact Cylinder ACPD100X110SB Is Used
Gantry lift-and-lower stations
The equal 3681.6 N force in both directions balances a vertical slide, lifting pallet trays of about 187 kg with a 2:1 margin on a packaging line gantry.
Twin-sided press fixture
A rod on each cover lets one cylinder clamp a housing from both sides in a machining cell, with the male M16x1.5 thread taking bolt-on tooling directly.
Position-monitored ejector
With the fitted -S magnet, CMSE or DMSE switches confirm full advance and retract of a scrap ejector on a stamping line, at speeds from 30-500 mm/s.
Replacing the Airtac ACPD Double Rod Compact Cylinder ACPD100X110SB with the ACED100X110SB
At 3681.6 N per direction at 0.5 MPa, the 100 mm bore is the top of the range; if your load needs less, the 80 mm bore delivers 2356.2 N the same way, and there is no larger standard bore in this family. The 110 mm stroke sits well inside the 300 mm maximum standard stroke for bore 100, so no made-to-order length is needed. Choose the male-thread rod (B code, M16x1.5) when your tooling bolts on, and remember a plain double-rod cylinder drifts when air is lost - add a rod lock or pilot check for a held load. FA/FB flange and LB foot mountings bolt to the ISO 21287 face. Since ACPD is discontinued, order the ACED100X110 as the current drop-in and verify the mounting dimensions first.
Replacement checklist
- ✓ Current-production ACE → ACED100X110SB
- ✓ Same bore / stroke / force class
- ✓ Confirm ISO 21287 mounting dimensions
- ✓ Port/thread type (PT / G)
- ✓ Add -S for magnet if you need sensors
Airtac ACPD Double Rod Compact Cylinder ACPD100X110SB FAQ
It is double acting with a rod exiting both covers, so force is equal both ways: 3681.6 N at 0.5 MPa and 5154.2 N at 0.7 MPa, on the rod-side area. Peak output at 1.0 MPa is 750.8 kgf. Operating range is 0.15-1.0 MPa (22-145 psi), proof 1.5 MPa (215 psi), speed 30-500 mm/s, port 1/4" PT, rod 25 mm with a male M16x1.5 thread.
The hard-anodized aluminium body follows the short ISO 21287-class format, saving about 50% of the mounting length of an ISO 15552 profile cylinder, with fixed TPU bumpers at both ends. The S code means the optional -S magnet is fitted, so CMSE / DMSE reed or solid-state switches can be mounted. The model is discontinued; the ACED100X110 is the current drop-in - confirm the ISO 21287 mounting dimensions before swapping.
