Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-100B
The AirTAC ACPJ Adjustable Compact Cylinder ACPJ12X100-100B is a double acting, double rod, adjustable stroke DIN-standard tight/compact air cylinder with a Ø12mm bore and 100mm stroke, M5×0.8 air ports and a hard-anodized aluminium body. This model is discontinued — the current-production replacement is the ACEJ12X100-100B (ISO 21287 ACE), in the same bore, stroke and force class.
- BoreØ12 mm
- Stroke100 mm
- Port sizeM5×0.8
- Acting typeDouble acting, double rod, adjustable stroke
- Rod threadM3×0.5
- StatusDiscontinued → ACEJ12X100-100B
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-100B
A double acting compact cylinder with adjustable stroke, the ACPJ12X100-100B runs on a 12 mm bore and delivers 56.5 N of push force and 42.4 N of pull force at 0.5 MPa (79.2 N / 59.4 N at 0.7 MPa). The -100 code sets a 100 mm adjustment window: an external stop screw trims the extend stroke anywhere within the ordered 100 mm range, so one cylinder can be tuned on the machine without swapping parts. The 100 mm stroke exceeds the 50 mm maximum standard stroke for this bore, so it is a non-standard, made-to-order build.
The short ISO 21287-class body saves about 50% of the mounting length of an ISO 15552 profile cylinder, which is why it suits tight jigs and guarding where a full-length body cannot fit. A fixed TPU bumper sits at both ends, the hard-anodized aluminium body carries an S45C hard-chrome rod, and the B code gives a male rod thread. Plan on roughly 34 N (about 3 kg of vertical lift with a 2:1 margin) of real work at 0.5 MPa rather than the full rating. Note: this model is discontinued; the current-production drop-in is the ACEJ12X100, so confirm ISO 21287 mounting dimensions before swapping.
Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-100B Technical Specifications
| Model | Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-100B |
|---|---|
| Series | ACPJ DIN compact cylinder (discontinued) |
| Replacement | ACEJ12X100-100B |
| Bore size | Ø12 mm |
| Stroke | 100 mm |
| Acting type | Double acting, double rod, adjustable stroke |
| Port size | M5×0.8 |
| Rod thread | M3×0.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed bumper (both ends) |
| Max standard stroke | Up to 50 mm |
Specifications follow the official AirTAC ACP datasheet (now discontinued). The ACEJ12X100-100B (ISO 21287) carries the same bore/stroke/force class; confirm mounting-interface dimensions against the ACE datasheet before installation. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G.
Theoretical Output Force (Ø12mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 42 N |
| 0.7 MPa | 59 N |
| Max (@1.0 MPa) | 9 kgf |
ACPJ is double-rod: the rear rod that carries the stroke adjuster exits the rear cover, so both piston faces lose rod area. The rod-side (annular) area is used for both directions (conservative).
Model Code: Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-100B
| ACPJ | DIN compact cylinder (adjustable-stroke, discontinued). |
|---|---|
| 12 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -100 | Adjustable stroke window (mm the extend stroke can be shortened on site). |
| S | Optional built-in magnet for sensor position sensing (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
Replacement mapping (swap P for E): ACP→ACE, ASP→ASE, ATP→ATE, ACPD→ACED, ACPJ→ACEJ. ACP-family: ACP (double acting), ASP / ATP (single acting push / pull), ACPD (double rod), ACPJ (double rod, adjustable stroke).
Where the Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-100B Is Used
Small-parts ejection in plastic molding
The 56.5 N push at 0.5 MPa is enough to kick finished caps or connectors off a mold nest, and the 100 mm adjustment window lets the operator dial the eject travel to the cavity depth.
Bottle and carton gating on packaging lines
A stop screw trimmed to the exact lane width diverts vials or cartons at up to 500 mm/s, and the short body slots into the narrow gap between conveyor frames.
Sample pressing in lab automation
About 3 kg of vertical lift with a 2:1 margin seats microplates or press-fit caps gently, and the male rod thread takes an I-type knuckle for aligned push motion.
Replacing the Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-100B with the ACEJ12X100-100B
At 12 mm bore this is the smallest force class in the range: 56.5 N push at 0.5 MPa. Step up to the 16 mm bore for 100.5 N or the 20 mm bore for 157.1 N if the load needs more headroom. The stop screw shortens the extend stroke only - it is a mechanical end stop, not a mid-stroke lock, so the piston still drifts if air is lost. Mounting uses FA/FB flange or LB foot on the ISO 21287 face, and position sensing requires the optional -S magnet code to work with CMSE / DMSE switches; this unit has no S code, so no magnet is fitted. Order the ACEJ12X100 as the current replacement.
Replacement checklist
- ✓ Current-production ACE → ACEJ12X100-100B
- ✓ Same bore / stroke / force class
- ✓ Confirm ISO 21287 mounting dimensions
- ✓ Port/thread type (PT / G)
- ✓ Add -S for magnet if you need sensors
Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-100B FAQ
At 0.5 MPa it pushes 56.5 N and pulls 42.4 N; at 0.7 MPa it pushes 79.2 N and pulls 59.4 N, with a theoretical maximum of 11.5 kgf at 1.0 MPa. The -100 code is a 100 mm adjustment window: an external stop screw shortens the extend stroke anywhere in the 0-100 mm range. It is a mechanical end stop only, so on air loss the piston still drifts. The 100 mm stroke is non-standard for this bore (50 mm max standard) and is made to order. The model is discontinued; the ACEJ12X100 is the current replacement.
The short ISO 21287-class body saves about 50% of the mounting length of an ISO 15552 profile cylinder, with FA/FB flange or LB foot mounting on the standard face. A fixed TPU bumper decelerates the piston at both ends. Position sensing needs the optional -S magnet code with CMSE / DMSE switches - this unit has no S code, so no magnet is fitted and no sensor can be mounted. Operating pressure is 0.15-1.0 MPa (22-145 psi), speed 30-500 mm/s, port M5x0.8, rod 6 mm with a male thread.
