Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-20
$49.74
Regular price
$57.24
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACPJ12X100-20
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with DIN standards in structural design;
2. Front/rear end caps feature threaded connections for enhanced strength and maintenance convenience;
3. Barrel undergoes precision machining followed by hard anodizing treatment for superior wear resistance and durability;
4. Specialized bidirectional sealing structure in piston design ensures compact dimensions with integrated oil reservoir functionality;
5. Space-optimized compact configuration minimizes installation footprint;
6. Perimeter magnetic switch grooves enable flexible sensor mounting options;
7. Multiple standardized mounting accessories available for system integration;
Category: Adjustable Cylinders | Brand: AirTAC | Series: ACPJ
Installation tip:
For optimal performance, maintain 0.5-1mm axial clearance during mounting.
Use lock nuts (included) for stroke limiter fixation after adjustment.
Lubricate with ISO VG32 hydraulic oil if operated below -10℃.
2. Front/rear end caps feature threaded connections for enhanced strength and maintenance convenience;
3. Barrel undergoes precision machining followed by hard anodizing treatment for superior wear resistance and durability;
4. Specialized bidirectional sealing structure in piston design ensures compact dimensions with integrated oil reservoir functionality;
5. Space-optimized compact configuration minimizes installation footprint;
6. Perimeter magnetic switch grooves enable flexible sensor mounting options;
7. Multiple standardized mounting accessories available for system integration;
Category: Adjustable Cylinders | Brand: AirTAC | Series: ACPJ
AirTAC ACPJ Adjustable Compact Cylinder ACPJ12X100-20 Specifications
- Model: ACPJ12X100-20
- Type: Adjustable stroke compact pneumatic cylinder
- Bore size: 12mm (0.47")
- Stroke: 100mm ±1mm (3.94")
- Adjustment range: ±5mm (±0.2") via built-in stroke limiter
- Operating pressure: 0.05–1.0 MPa (7-145 PSI)
- Cushioning: Elastic buffer + adjustable end position locking
- Mounting type: Basic type (optional accessories: MA04/MA05 mounts)
- Port size: M5x0.8 (Rc1/8/NPT1/8 optional)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Piston material: Aluminum alloy hard anodized
- Rod material: Chrome-plated steel (Cr coating thickness 15-20μm)
- Seal material: NBR (Nitrile rubber)
- Weight: 380g ±5g (0.84 lbs)
- Dimensions:
- Extended length: 165mm (6.50")
- Retracted length: 65mm (2.56")
- Body diameter: Φ32mm (1.26")
- Rod end thread: M6x1.0
- ISO standard: 6432 (compact series)
- Accessory ready: Built-in magnet for magnetic sensor (D-M9N series compatible)
Ultra-compact cylinder with integrated stroke adjustment mechanism, featuring a space-saving design that reduces 25% installation space compared to standard cylinders. The dual-cushion structure minimizes end-impact noise (≤65dB) while maintaining positioning repeatability of ±0.3mm. Includes anti-rotation guide for precise linear motion.
Typical Applications:
- PCB handling robots in semiconductor manufacturing
- Precision clamping devices for CNC tool changers
- Dosing valve actuators in pharmaceutical packaging
- Z-axis positioners for 3D printing extruders
- Automated test equipment probe positioning
Installation tip:
For optimal performance, maintain 0.5-1mm axial clearance during mounting.
Use lock nuts (included) for stroke limiter fixation after adjustment.
Lubricate with ISO VG32 hydraulic oil if operated below -10℃.
Cycle life:
5,000km travel distance or 10 million cycles (whichever comes first)
under standard operating conditions (0.5MPa, 20℃, clean dry air)
| Property | Property Value |
|---|---|
| sku | ACPJ12X100-20 |
| Adjustable Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | 100mm |
