Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-50B
2. Front/rear end caps feature threaded connections for enhanced strength and maintenance convenience;
3. Barrel undergoes precision machining followed by hard anodizing treatment for superior wear resistance and durability;
4. Specialized bidirectional sealing structure in piston design ensures compact dimensions with integrated oil reservoir functionality;
5. Space-optimized compact configuration minimizes installation footprint;
6. Perimeter magnetic switch grooves enable flexible sensor mounting options;
7. Multiple standardized mounting accessories available for system integration;
Category: Adjustable Cylinders | Brand: AirTAC | Series: ACPJ
AirTAC ACPJ Adjustable Compact Cylinder ACPJ12X100-50B Technical Specifications
- Model Code: ACPJ12X100-50B
- Series: ACPJ (Adjustable Cushion Compact Cylinder)
- Bore Size: 12mm
- Stroke: 100mm ±0.5mm tolerance
- Operating Pressure: 0.05-1.0 MPa
- Cushion Type: Adjustable pneumatic cushion (both ends)
- Mounting Style: Basic foot mounting (ISO 15552 standard)
- Port Size: M5x0.8 (Rc1/8/NPT1/8 optional)
- Piston Speed: 50-750 mm/s (lubricated)
- Ambient Temperature: -20℃ to 80℃
- Piston Material: Aluminum alloy with hard anodized surface
- Rod Material: Chrome-plated steel (Cr equivalent ≥0.8μm)
- Seal Type: NBR+PU combination seals
- Repeat Positioning Accuracy: ±0.1mm
- Weight: 0.45kg ±3% (excluding accessories)
- Dimensions:
- Extended Length: 195mm
- Retracted Length: 95mm
- Body Width: 34mm
- Mounting Height: 18mm
- ISO Certification: 6431, VDMA 24562
This space-optimized cylinder features twin adjustable pneumatic cushions for precise end-position deceleration control, reducing impact noise by 15dB compared to standard models. The 50B variant includes an integrated mounting groove for sensor installation. Special rod seal design ensures ≤0.3mm leakage at 0.5MPa after 1,000km stroke testing.
- PCB board handling robots (anti-vibration critical)
- Pharmaceutical blister packaging machines
- Automated optical inspection (AOI) equipment positioning
- Semiconductor wafer transfer systems
- Textile machinery thread tension control
Maintenance Protocol:
Lubricate every 3 months with ISO VG32 hydraulic oil (0.3-0.5cc).
Avoid angular misalignment exceeding ±2° during installation.
Maximum side load capacity: 12N at full extension.
| Property | Property Value |
|---|---|
| sku | ACPJ12X100-50B |
| Adjustable Stroke | <50mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | 100mm |
