Airtac ACQ Ultra Thin Air Cylinder ACQ12X15S
2. Features C-shaped retaining rings for securing cylinder body to front/rear covers, with riveted piston-rod assembly ensuring compactness and reliability;
3. Precision-honed bore surface enhances wear resistance and operational longevity;
4. Extended front cover guiding system improves alignment stability;
5. Space-saving profile maximizes installation flexibility in confined spaces;
6. Integrated sensor grooves along cylinder periphery facilitate seamless sensor mounting;
7. Comprehensive selection of standardized mounting accessories available;
Category: Compact Cylinders | Brand: AIRTAC | Series: ACQ
AirTAC ACQ12X15S Ultra-Thin Cylinder Specifications
- Model: ACQ12X15S
- Type: Single-acting spring return (compact series)
- Bore size: 12mm
- Stroke: 15mm (±1mm tolerance)
- Operating pressure: 0.15-0.8 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Rubber buffer (non-adjustable)
- Port thread: M5×0.8 (dual ports)
- Mounting: 2x M5 threaded holes (20mm center spacing)
- Piston speed: 50-500mm/s (lubricated condition)
- Seal material: NBR + Special polyurethane blend
- Weight: 0.15kg (excluding accessories)
- Dimensions:
- Body length: 32mm
- Total extended length: 47mm (32+15mm stroke)
- Width: 20mm
- Height: 20mm
- ISO standard: 6432 compliant (compact cylinder specifications)
Featuring a 60% slimmer profile than standard cylinders, the ACQ12X15S delivers 8N thrust at 0.5MPa with precision linear motion. Its anodized aluminum construction resists chemical corrosion while maintaining 500km service life under standard conditions. Requires 5μm filtered air with ISO 8573-1 class 3 purity.
- PCB board clamping in electronics assembly
- Micro-dosing valves in pharmaceutical packaging
- Precision paper feeding mechanisms
- Robotic end-effector positioning systems
- Medical device actuation components
Installation guidelines:
Maintain 0.05mm maximum lateral misalignment during mounting.
For vertical installations, use model with "V" suffix for enhanced
spring retention. Lubricate every 3 million cycles with ISO VG32
pneumatic oil.
| Property | Property Value |
|---|---|
| sku | ACQ12X15S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <15mm> |
