Airtac ACQ Ultra Thin Air Cylinder ACQ12X15SB
2. Features C-shaped retaining rings for securing cylinder body to front/rear covers, with riveted piston-rod assembly ensuring compactness and reliability;
3. Precision-honed bore surface enhances wear resistance and operational longevity;
4. Extended front cover guiding system improves alignment stability;
5. Space-saving profile maximizes installation flexibility in confined spaces;
6. Integrated sensor grooves along cylinder periphery facilitate seamless sensor mounting;
7. Comprehensive selection of standardized mounting accessories available;
Category: Compact Cylinders | Brand: AIRTAC | Series: ACQ
AirTAC ACQ12X15SB Ultra-Slim Cylinder Specifications
- Model: ACQ12X15SB
- Series: ACQ (Compact Square Cylinder)
- Bore size: 12mm
- Stroke: 15mm (adjustable cushion)
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -20℃ to 80℃
- Port size: M5x0.8 (standard)
- Piston speed: 50–800 mm/s
- Cushion type: Rubber buffer (both ends)
- Seal material: NBR + PU combination
- Rod material: Stainless steel (SUS304)
- Body material: Aluminum alloy (anodized)
- Weight: 0.13 kg ±5%
- Dimensions:
- Length: 63mm (including rod)
- Width: 20mm (square body)
- Height: 20mm (square body)
- ISO standard: 6432 compliant
- Mounting options: Female thread (standard), optional flange kits
The ACQ12X15SB features a 3.5mm ultra-thin wall design with square profile for space-constrained automation. Its precision-machined guide slots ensure smooth linear motion while maintaining ±0.2mm repeat positioning accuracy. The dual-purpose lubrication ports allow both grease injection and air purge cleaning.
- PCB handling robots in electronics manufacturing
- Micro-dosing mechanisms in medical devices
- Camera module positioning systems
- Precision clamping in watch assembly
- Automated test equipment (ATE) actuators
Installation note:
Optimal performance achieved when mounted horizontally. Use VG32 grade pneumatic oil for lubrication.
Avoid side load exceeding 2N·m. Alignment tolerance: ±0.5° angular misalignment max.
| Property | Property Value |
|---|---|
| sku | ACQ12X15SB |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <15mm> |
