Airtac ACQ Ultra Thin Air Cylinder ACQ12X15SBCB
2. Features C-shaped retaining rings for securing cylinder body to front/rear covers, with riveted piston-rod assembly ensuring compactness and reliability;
3. Precision-honed bore surface enhances wear resistance and operational longevity;
4. Extended front cover guiding system improves alignment stability;
5. Space-saving profile maximizes installation flexibility in confined spaces;
6. Integrated sensor grooves along cylinder periphery facilitate seamless sensor mounting;
7. Comprehensive selection of standardized mounting accessories available;
Category: Compact Cylinders | Brand: AIRTAC | Series: ACQ
AirTAC ACQ12X15SBCB Ultra-Thin Cylinder Specifications
- Model: ACQ12X15SBCB
- Type: Double-acting ultra-slim cylinder
- Bore size: 12mm
- Stroke: 15mm
- Material: Aluminum alloy cylinder tube, stainless steel piston rod
- Seal material: NBR (nitrile rubber)
- Operating pressure: 0.15–0.8 MPa
- Cushion type: Rubber buffer (both ends)
- Temperature range: -20℃ to 80℃
- Weight: 0.22kg
- Dimensions: 80mm(L) × 24mm(W) × 25mm(H)
- Mounting style: Standard (optional accessories: MF12/MB12/MK12 series mounts)
- Port size: M5x0.8 (dual ports)
- Piston speed: 50–800mm/s (lubricated)
- ISO standard: 6432 compliant
Space-optimized pneumatic cylinder featuring 34% reduced height compared to standard ISO cylinders. Precision-machined guide mechanism ensures smooth linear motion with minimal wobble. Pre-lubricated for immediate installation, with wear-resistant chromium-plated piston rod surface (Ra ≤0.4μm). Compatible with all standard pneumatic fittings.
- PCB handling robots in electronics assembly
- Medical device positioning mechanisms
- Compact packaging machine actuators
- Semiconductor wafer processing equipment
- Automated optical inspection (AOI) systems
Installation note:
Maintain parallel alignment with driven components (±0.5° tolerance). Use AirTAC UC-1 grease for re-lubrication every 3,000km of cumulative travel. Avoid side-load forces exceeding 3N.
| Property | Property Value |
|---|---|
| sku | ACQ12X15SBCB |
| Mounting Type | Double Ear Fixed Mount |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <15mm> |
