Airtac ACQ Ultra Thin Air Cylinder ACQ12X25
2. Features C-shaped retaining rings for securing cylinder body to front/rear covers, with riveted piston-rod assembly ensuring compactness and reliability;
3. Precision-honed bore surface enhances wear resistance and operational longevity;
4. Extended front cover guiding system improves alignment stability;
5. Space-saving profile maximizes installation flexibility in confined spaces;
6. Integrated sensor grooves along cylinder periphery facilitate seamless sensor mounting;
7. Comprehensive selection of standardized mounting accessories available;
Category: Compact Cylinders | Brand: AIRTAC | Series: ACQ
AirTAC ACQ12X25 Ultra-Slim Cylinder Specifications
- Model: ACQ12X25
- Type: Single-acting spring return cylinder
- Bore size: 12mm
- Stroke: 25mm
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5×0.8 (Standard) / NPT1/8 (Optional)
- Piston speed: 50–800 mm/s
- Mounting style: Standard (Basic) / Fixed (Optional)
- Cushioning: Rubber buffer (Adjustable cushion optional)
- Seal material: NBR (Nitrile) / PU (Polyurethane) available
- Rod material: Stainless steel (SUS304)
- Weight: 0.18kg (Cylinder body only) / 0.23kg (With accessories)
- Dimensions:
- Body length: 53mm
- Extended length: 78mm (25mm stroke)
- Width: 20mm (Mounting base)
- Height: 30mm (Including rod end)
Ultra-compact pneumatic cylinder optimized for space-constrained automation systems. Features precision-ground rod and self-lubricating bushings for smooth operation. The anodized aluminum body provides corrosion resistance in humid environments. Requires 5μm filtered air (ISO 8573-1:2010 Class 3.4.2) for optimal performance.
- PCB handling robots in electronics assembly
- Micro-precision clamping in watch manufacturing
- Medical device actuators requiring hygienic design
- Packaging machine ejector mechanisms
- Semiconductor wafer processing equipment
Installation tip:
Use precision alignment jigs during mounting to prevent side load.
For vertical installations exceeding 45° angle, apply 0.03MPa minimum
pressure to overcome spring resistance. Lubricate monthly with ISO VG32
turbine oil in high-cycle applications (＞1 million cycles/year).
| Property | Property Value |
|---|---|
| sku | ACQ12X25 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <25 mm> |
