Airtac ACQ Ultra Thin Air Cylinder ACQ50X40S
2. Features C-shaped retaining rings for securing cylinder body to front/rear covers, with riveted piston-rod assembly ensuring compactness and reliability;
3. Precision-honed bore surface enhances wear resistance and operational longevity;
4. Extended front cover guiding system improves alignment stability;
5. Space-saving profile maximizes installation flexibility in confined spaces;
6. Integrated sensor grooves along cylinder periphery facilitate seamless sensor mounting;
7. Comprehensive selection of standardized mounting accessories available;
Category: Compact Cylinders | Brand: AIRTAC | Series: ACQ
AirTAC ACQ50X40S Ultra-Thin Cylinder Specifications
- Model: ACQ50X40S
- Bore size: 50mm
- Stroke: 40mm
- Action type: Single-acting (spring return)
- Operating pressure: 0.15–0.8 MPa
- Cushioning: Adjustable rubber buffer
- Port size: PT1/4 (G1/8 optional)
- Temperature range: -20℃ to 80℃
- Seal material: NBR (Nitrile Butadiene Rubber)
- Mounting type: Basic type (with axial mounting holes)
- Weight: 0.95kg (excluding accessories)
- Dimensions: 100mm(L) × 50mm(W) × 50mm(H)
- Piston rod material: Hard chrome-plated carbon steel
- Tube material: Anodized aluminum alloy
- Maximum speed: 500mm/s
- ISO standard: Compliant with ISO 15552 mounting dimensions
The ACQ50X40S features a revolutionary low-profile design with 35% reduced installation height compared to standard cylinders. Its compact structure integrates precision-machined guide slots for enhanced lateral load capacity. The dual-seal piston design ensures leak-free operation even under high-cycle conditions (up to 1.5 million cycles). Requires filtered compressed air with 5-40μm filtration and lubrication (ISO VG32 recommended).
- High-density automation cells in electronics assembly
- Medical device positioning mechanisms
- Packaging machine clamp actuators
- Cleanroom-compatible automation systems
- Robotic end-effector tool changers
- Food processing equipment (oil-resistant version available)
Installation guidelines:
Maintain 0.05mm maximum misalignment during mounting.
For vertical installations, use auxiliary rod support brackets.
Lubricate through port weekly in dry air conditions.
| Property | Property Value |
|---|---|
| sku | ACQ50X40S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | <40mm> |
