Airtac ACQ125 Slim Cylinder ACQ125X100SB
1. Compliant with JIS (Japanese Industrial Standards) specifications;
2. Features C-shaped retaining ring for cylinder body and end cover fixation, ensuring compactness and reliability;
3. Precision-machined bore with hard anodized treatment for enhanced wear resistance and durability;
4. Asymmetric bidirectional sealing structure on piston for compact dimensions and integrated oil storage capability;
5. Space-saving profile design to optimize installation space utilization;
6. Built-in sensor grooves along the cylinder periphery for effortless sensor integration.
Category: Slim Cylinder , Brand: AIRTAC , Series: ACQ125
AirTAC ACQ125X100SB Compact Cylinder Specifications
- Model: ACQ125X100SB
- Type: ISO 21287-compliant compact cylinder
- Bore size: 125mm
- Stroke: 100mm (±1.5mm tolerance)
- Operating pressure: 0.05–1.0 MPa
- Ambient temperature: -20℃ to 80℃
- Cushioning: Rubber buffer + adjustable shock absorber
- Mounting style: Basic foot mounting (SB series)
- Port size: G3/8 (ISO 228 standard)
- Piston rod thread: M16×1.5
- Material: Aluminum alloy barrel, hardened steel piston rod
- Seal material: NBR with wear-resistant ring
- Weight: 0.85kg (dry, without accessories)
- Dimensions: 225mm(L) × 125mm(W) × 125mm(H)
Ultra-flat cylinder designed for space-constrained automation systems, featuring 30% reduced installation height compared to standard cylinders. The precision-ground piston rod incorporates chrome-plated surface treatment (2-3μm thickness) for enhanced corrosion resistance. Integrated magnet slot supports position sensing compatibility with SNS series sensors.
- High-density pick-and-place systems in electronics assembly
- Clamping mechanisms in CNC machine tool changers
- Vertical lifting platforms in packaging machinery
- Material handling robots with limited envelope space
- Medical device actuation requiring smooth linear motion
Installation note:
Lubricate with ISO VG32 hydraulic oil before initial operation.
Maximum side load capacity: 15N at full extension.
For vertical mounting, use auxiliary guide mechanisms when handling >5kg payloads.
| Property | Property Value |
|---|---|
| sku | ACQ125X100SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 125mm |
| Stroke | 100mm |
