Airtac ACQ125 Slim Cylinder ACQ125X125SB
1. Compliant with JIS (Japanese Industrial Standards) specifications;
2. Features C-shaped retaining ring for cylinder body and end cover fixation, ensuring compactness and reliability;
3. Precision-machined bore with hard anodized treatment for enhanced wear resistance and durability;
4. Asymmetric bidirectional sealing structure on piston for compact dimensions and integrated oil storage capability;
5. Space-saving profile design to optimize installation space utilization;
6. Built-in sensor grooves along the cylinder periphery for effortless sensor integration.
Category: Slim Cylinder , Brand: AIRTAC , Series: ACQ125
AirTAC ACQ125X125SB Compact Cylinder Specifications
- Model: ACQ125X125SB
- Type: Single-acting spring return (thin series)
- Bore size: 125mm
- Stroke: 125mm
- Operating pressure: 0.05-0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushion type: Adjustable rubber buffer
- Port size: G1/2 (ISO228/1 standard)
- Mounting style: Basic type (no built-in mounts)
- Piston rod thread: M20×1.5
- Material:
- Tube: Aluminum alloy hard anodized
- Piston rod: Chrome-plated steel
- Seals: NBR (Nitrile rubber)
- Weight: 5.8kg (without accessories)
- Dimensions:
- Overall length (extended): 250mm
- Body diameter: 145mm
- Stroke tolerance: ±1.5mm
- Rod end dimensions: 35×35mm mounting face
Ultra-flat cylinder designed for space-constrained automation systems, featuring 40% reduced axial length compared to standard cylinders. The double-sealed piston design achieves ≤0.5mm/s creep speed at 0.5MPa. Integrated wear-resistant guide rings ensure smooth operation over 5,000km service life. Requires 5μm filtered air with ISO 8573-1:2010 class 3 air quality.
- High-density packaging line pusher mechanisms
- Automotive welding fixture clamping
- Lithium battery press molding machines
- Semiconductor wafer handling robots
- Vertical CNC tool changers
Installation guidelines:
Maximum side load ≤15% of thrust rating. For vertical mounting,
use M20 locknut (3Nm torque) to prevent rod rotation. Lubricate
rod with ISO VG32 hydraulic oil monthly in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | ACQ125X125SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 125mm |
| Stroke | 125mm |
