Airtac ACQ125 Slim Cylinder ACQ125X125SBH
1. Compliant with JIS (Japanese Industrial Standards) specifications;
2. Features C-shaped retaining ring for cylinder body and end cover fixation, ensuring compactness and reliability;
3. Precision-machined bore with hard anodized treatment for enhanced wear resistance and durability;
4. Asymmetric bidirectional sealing structure on piston for compact dimensions and integrated oil storage capability;
5. Space-saving profile design to optimize installation space utilization;
6. Built-in sensor grooves along the cylinder periphery for effortless sensor integration.
Category: Slim Cylinder , Brand: AIRTAC , Series: ACQ125
AirTAC ACQ125X125SBH Compact Cylinder Specifications
- Model: ACQ125X125SBH
- Type: Single-acting spring return (Thin series)
- Bore size: 125mm
- Stroke: 125mm (Customizable: 25-300mm)
- Operating pressure: 0.05-0.9 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer + shock absorber
- Mounting style: Basic foot mounting (MF1)
- Port size: PT1/2 (G1/2 optional)
- Seal material: High-grade NBR with wear-resistant ring
- Piston rod material: Hard chrome-plated carbon steel
- Repeat positioning accuracy: ±0.5mm
- Max speed: 500mm/s
- Weight: 5.8kg (Excluding accessories)
- Dimensions: 252mm(L) × 145mm(W) × 145mm(H)
Ultra-flat cylinder engineered for high thrust requirements in confined spaces, featuring 40% reduced axial length compared to standard cylinders. The dual-seal design with integrated guide mechanism ensures precise linear motion, while the anodized aluminum body provides corrosion resistance in humid environments. Requires 5μm filtered air with ISO 8573-1:2010 Class 3.4.2 quality.
- Automated palletizing systems in logistics
- Die-casting machine ejection mechanisms
- Heavy-duty clamping fixtures for CNC machining
- Steel mill conveyor gate controls
- Automotive press line material handling
Maintenance tip:
Lubricate guide bushings every 500,000 cycles using ISO VG32 hydraulic oil.
Avoid side load exceeding 15% of maximum thrust capacity.
| Property | Property Value |
|---|---|
| sku | ACQ125X125SBH |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 125mm |
| Stroke | 125mm |
