Airtac ACQ160 Slim Cylinder ACQ160X125S
1. Compliant with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, ensuring compact and robust construction;
3. Bore surface undergoes precision machining followed by hard anodizing treatment, delivering superior wear resistance and extended service life;
4. Asymmetric bidirectional sealing structure on piston provides space-efficient design with integrated oil reservoir feature;
5. Compact profile optimizes space utilization in confined installation environments;
6. Perimeter sensor grooves enable convenient magnetic switch mounting.
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQ160 （Note: Key technical terms optimized for industry usage include "hard anodizing", "asymmetric bidirectional sealing", "oil reservoir feature", and "perimeter sensor grooves" to maintain professional accuracy while enhancing international readability.）
AirTAC ACQ160X125S Ultra-Thin Cylinder Specifications
- Model: ACQ160X125S
- Type: Double-acting ultra-slim cylinder
- Bore size: 16mm (0.63")
- Stroke: 125mm (4.92")
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Cushion type: Padded cushion (both ends)
- Mounting style: Foot mounting (NF series compatible)
- Material: Aluminum alloy (cylinder barrel), Stainless steel (piston rod)
- Seal material: NBR rubber (nitrile butadiene)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Port size: M5x0.8 or PT1/8 (user configurable)
- Weight: 0.45kg (0.99 lbs)
- Dimensions: 285mm(L) × 30mm(W) × 30mm(H) (11.22"×1.18"×1.18")
- Piston rod thread: M6x1.0
- Maximum speed: 500mm/s
- Lubrication: Pre-lubricated (non-relubrication design)
The ACQ160X125S features a space-saving profile (30% thinner than standard cylinders) with full-stroke stability. Its anodized barrel resists corrosion while maintaining precise air sealing through dual piston seals. The integrated cushioning mechanism minimizes end-impact noise below 75dB. Designed for ISO 6432 compliance with enhanced lateral load capacity (max 15N).
- High-density automation cells in electronics assembly
- Cartesian robot Z-axis actuation
- Medical device lid-clamping mechanisms
- Packaging machine reject-arm systems
- Semiconductor wafer handling equipment
Installation tip:
Maintain ≤0.1mm/m alignment tolerance during mounting. Use C-shaped retaining rings
(included) for tool-free stroke adjustment. Avoid side load exceeding 10% of maximum thrust.
| Property | Property Value |
|---|---|
| sku | ACQ160X125S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 125mm |
| Stroke | 125mm |
