Airtac ACQ160 Slim Cylinder ACQ160X200S
1. Compliant with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, ensuring compact and robust construction;
3. Bore surface undergoes precision machining followed by hard anodizing treatment, delivering superior wear resistance and extended service life;
4. Asymmetric bidirectional sealing structure on piston provides space-efficient design with integrated oil reservoir feature;
5. Compact profile optimizes space utilization in confined installation environments;
6. Perimeter sensor grooves enable convenient magnetic switch mounting.
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQ160 （Note: Key technical terms optimized for industry usage include "hard anodizing", "asymmetric bidirectional sealing", "oil reservoir feature", and "perimeter sensor grooves" to maintain professional accuracy while enhancing international readability.）
AirTAC ACQ160X200S Ultra-Thin Cylinder Specifications
- Model: ACQ160X200S
- Bore size: 16mm
- Stroke: 200mm
- Operating pressure: 0.15–0.8 MPa
- Medium: Clean compressed air (ISO8573-1:2010 Class 3)
- Ambient temperature: -20℃ to 80℃
- Piston speed: 50–800 mm/s
- Cushion type: Rubber buffer (adjustable both ends)
- Port size: M5x0.8 (G1/8 optional)
- Mounting type: Basic type (accessory mounts available)
- Seal material: NBR (HNBR optional)
- Protection rating: IP65 (standard rod wiper)
- Weight: 0.75kg ±3%
- Dimensions: 260mm(L) × 25mm(W) × 25mm(H)
Ultra-compact cylinder achieving 25% thinner profile than standard models through optimized internal structure. Features precision honed aluminum barrel with hard anodized finish (8-12μm) for extended wear resistance. Includes built-in magnet for sensor attachment (S model designation).
- PCB handling robots in electronics assembly
- Medical device actuation systems
- High-density packaging line diverters
- Semiconductor wafer processing equipment
- Automated optical inspection (AOI) mechanisms
Installation guidance:
For vertical mounting, reduce maximum load by 30%. Use locking nuts (M3)
for vibration-prone applications. Lubricate through air port monthly with
ISO VG32 class turbine oil. Avoid side load exceeding 15N.
| Property | Property Value |
|---|---|
| sku | ACQ160X200S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 125mm |
| Stroke | <200mm> |
