Airtac ACQ160 Slim Cylinder ACQ160X30SBH
$338.68
Regular price
$346.18
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACQ160X30SBH
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
ACQ160 Ultra-Thin Cylinder
1. Compliant with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, ensuring compact and robust construction;
3. Bore surface undergoes precision machining followed by hard anodizing treatment, delivering superior wear resistance and extended service life;
4. Asymmetric bidirectional sealing structure on piston provides space-efficient design with integrated oil reservoir feature;
5. Compact profile optimizes space utilization in confined installation environments;
6. Perimeter sensor grooves enable convenient magnetic switch mounting.
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQ160 （Note: Key technical terms optimized for industry usage include "hard anodizing", "asymmetric bidirectional sealing", "oil reservoir feature", and "perimeter sensor grooves" to maintain professional accuracy while enhancing international readability.）
Installation note:
For vertical mounting applications exceeding 2Hz cycle rate, use auxiliary rod-end support. Lubricate with ISO VG32 hydraulic oil if operating below 0℃. Avoid lateral loads exceeding 3N to prevent rod deflection.
1. Compliant with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, ensuring compact and robust construction;
3. Bore surface undergoes precision machining followed by hard anodizing treatment, delivering superior wear resistance and extended service life;
4. Asymmetric bidirectional sealing structure on piston provides space-efficient design with integrated oil reservoir feature;
5. Compact profile optimizes space utilization in confined installation environments;
6. Perimeter sensor grooves enable convenient magnetic switch mounting.
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQ160 （Note: Key technical terms optimized for industry usage include "hard anodizing", "asymmetric bidirectional sealing", "oil reservoir feature", and "perimeter sensor grooves" to maintain professional accuracy while enhancing international readability.）
AirTAC ACQ160X30SBH Ultra-Thin Cylinder Specifications
- Model: ACQ160X30SBH
- Type: Double-acting ultra-slim cylinder with magnetic piston
- Bore size: 16mm (ISO 6432 standard)
- Stroke: 30mm (±1mm tolerance)
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning type: Fixed rubber buffer
- Mounting style: Front flange with through-hole (NFI pattern)
- Port size: M5x0.8 (dual ports on both ends)
- Piston rod thread: M6x1.0 external thread
- Material:
- Cylinder tube: Aluminum alloy (hard anodized)
- Piston rod: Stainless steel SUS304
- Seals: NBR (nitrile rubber)
- Weight: 0.25kg (without accessories)
- Dimensions:
- Total length: 98mm (at mid-stroke)
- Body width: 20mm (excluding mounting tabs)
- Height: 26mm (including piston rod)
- Max theoretical force: 20.1N @0.5MPa (extending)
- Air consumption: 6.0cm³/stroke @0.5MPa
- Response time: ≤0.3s @0.5MPa
- Position detection: Compatible with SNS-M series magnetic sensors
This space-saving pneumatic cylinder features a 40% slimmer profile than standard models while maintaining robust 1.0MPa pressure capacity. The precision-ground piston rod incorporates wear-resistant chromium plating, and the integrated magnetic piston enables non-contact position sensing. Optimized for high-speed cycling up to 5Hz with minimal vibration transmission.
Typical Applications:
- PCB handling robots in electronics assembly
- Micro-dosing valves in pharmaceutical packaging
- Lens positioning systems in optical equipment
- Paper feed mechanisms in POS printers
- Automated test probe actuators
Installation note:
For vertical mounting applications exceeding 2Hz cycle rate, use auxiliary rod-end support. Lubricate with ISO VG32 hydraulic oil if operating below 0℃. Avoid lateral loads exceeding 3N to prevent rod deflection.
| Property | Property Value |
|---|---|
| sku | ACQ160X30SBH |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 125mm |
| Stroke | 30mm |
