Airtac ACQ160 Slim Cylinder ACQ160X50SB
$299.60
Regular price
$307.10
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACQ160X50SB
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
ACQ160 Ultra-Thin Cylinder
1. Compliant with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, ensuring compact and robust construction;
3. Bore surface undergoes precision machining followed by hard anodizing treatment, delivering superior wear resistance and extended service life;
4. Asymmetric bidirectional sealing structure on piston provides space-efficient design with integrated oil reservoir feature;
5. Compact profile optimizes space utilization in confined installation environments;
6. Perimeter sensor grooves enable convenient magnetic switch mounting.
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQ160 （Note: Key technical terms optimized for industry usage include "hard anodizing", "asymmetric bidirectional sealing", "oil reservoir feature", and "perimeter sensor grooves" to maintain professional accuracy while enhancing international readability.）
Operational note:
Requires ISO VG32 or equivalent turbine oil lubrication (1-2 drops per 1 million cycles).
Avoid side loads exceeding 1.5N·m. For vertical mounting, use spring-down orientation.
1. Compliant with JIS standards;
2. C-shaped retaining ring secures cylinder body to front/rear covers, ensuring compact and robust construction;
3. Bore surface undergoes precision machining followed by hard anodizing treatment, delivering superior wear resistance and extended service life;
4. Asymmetric bidirectional sealing structure on piston provides space-efficient design with integrated oil reservoir feature;
5. Compact profile optimizes space utilization in confined installation environments;
6. Perimeter sensor grooves enable convenient magnetic switch mounting.
Category: Slim Cylinder | Brand: AIRTAC | Series: ACQ160 （Note: Key technical terms optimized for industry usage include "hard anodizing", "asymmetric bidirectional sealing", "oil reservoir feature", and "perimeter sensor grooves" to maintain professional accuracy while enhancing international readability.）
AirTAC ACQ160X50SB Ultra-Thin Cylinder Specifications
- Model: ACQ160X50SB
- Type: Single-acting spring return (push type)
- Bore size: 16mm
- Stroke: 50mm (±1.5mm tolerance)
- Operating pressure: 0.05–0.7 MPa
- Ambient temperature: -10℃ to 60℃
- Cushion type: Fixed rubber bumper
- Port size: M5×0.8 (Standard) / NPT1/8 (Optional)
- Piston speed: 50–700 mm/s
- Mounting type: Basic type (no built-in mounts)
- Weight: 0.23 kg (without accessories)
- Dimensions: 92mm(L) × 20mm(W) × 20mm(H)
- Rod end thread: M5×0.8 (Female)
- Material: Aluminum alloy body, NBR seals
- Protection rating: IP54 (standard sealing)
Ultra-compact cylinder with 20mm profile height, optimized for space-constrained automation systems. Features a precision-ground stainless steel piston rod (Cr16 series) with hard chrome plating (3-5μm thickness). The double-sealed design prevents external contamination while maintaining ≤0.5 Nm breakaway friction.
Typical Applications:
- PCB handling robots in electronics manufacturing
- Medical device actuation mechanisms
- Automated test equipment positioners
- Compact packaging machine clamps
- Semiconductor wafer processing tools
Operational note:
Requires ISO VG32 or equivalent turbine oil lubrication (1-2 drops per 1 million cycles).
Avoid side loads exceeding 1.5N·m. For vertical mounting, use spring-down orientation.
Performance Characteristics:
- Startup pressure: ≤0.03 MPa
- Leakage rate: ≤5 cm³/min @ 0.5 MPa
- Repeat positioning accuracy: ±0.1mm
- Maximum kinetic energy: 0.12 J
| Property | Property Value |
|---|---|
| sku | ACQ160X50SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 125mm |
| Stroke | <50mm> |
